Danfoss / Eaton AIRBrake Tubing YELLOW

Description & Features

Designed specifically for heavy-duty applications, the Synflex by Danfoss / Eaton AIRBrake Tubing in yellow is an ideal choice for truck and trailer air brake systems. Its superior abrasion resistance and UV-stabilized cover ensure maximum durability, even under harsh conditions. Constructed from a high-quality proprietary blended nylon material, this extruded tubing offers lightweight flexibility, enhancing the overall performance of air brake harness assemblies and auxiliary air systems.

Meeting stringent industry standards, this tubing is certified to SAE J844, SAE J1131, and SAE J2494-3, and complies with DOT FMVSS 106. With a non-conductive design and a minimum bend radius of just 1 inch, it is engineered to fit a variety of configurations while delivering reliable performance. The vibrant yellow color aids in easy identification during installation and maintenance. This product is available in dash size -4, with a tube width of 0.25 inches, ensuring compatibility with a wide range of systems.

SKU: 4247-0414-0500

Supplier Part Number (MPN): 4247-0414-0500

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00803X01559	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J844\|SAE J1131\|SAE J2494-3	Color Yellow	Compliances DOT FMVSS 106	Conductivity 13552	Construction Extruded	Cover Material UV Stabilized	Dash Size -4	Brand Danfoss (IGS)	Brand Danfoss Power Solutions	Pack Size 1.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 1	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.25	Reinforcement Material None	Sub Brand Synflex	Supplier Part Number 4247-0414-0500	Tube Material Polyamide Alloy	Product Weight 7.50 lbs

Product Questions & Answers (1)

Question by: Lee S on Nov 9, 2025, 8:40 AM

Will this work alright for hooking up the air brakes on my old flatbed trailer?

Answer by: Customer Support on Nov 10, 2025, 11:00 AM

This Synflex tubing is DOT FMVSS 106 compliant and SAE J844 certified, so it's definitely suitable for truck and trailer air brake systems. Just make sure the -4 dash size and 0.25 inch tube width match your setup.
