4247 Solstice

Description & Features

The Eaton Aeroquip Synflex Solstice 4247 airbrake hose features a UV-stabilized cover material and proprietary blended nylon construction for maximum durability in harsh operating conditions.

This green, non-conductive hose is lightweight to improve flexibility, and is suitable for truck and trailer air brake systems, auxiliary air systems, and air brake harness assemblies.

The 4247 Solstice hose meets DOT FMVSS 106 compliance standards as well as SAE J844, SAE J2494-3 and SAE J1131 certifications. It offers premium abrasion resistance and a minimum bend radius of 1 inch, with a minimum working temperature of -40 degrees.

SKU: 4247-0415-0100

Supplier Part Number (MPN): 4247-0415-0100

Specifications

Abrasion Resistance 28	Alternate Part Numbers Alternate Part Number MINO-00803X01566	Application Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies.	Certifications SAE J844\|SAE J2494-3\|SAE J1131	Color Green	Compliances DOT FMVSS 106	Conductivity 13552	Construction Extruded	Cover Material UV Stabilized	Dash Size -4	Brand Danfoss Power Solutions (II LLC Aeroquip)	Brand Aeroquip	Pack Size 1.00	UOM FT	Features Light weight to improve hose flexibility\|Maximum durability under harsh operating conditions\|High quality proprietary blended nylon materials	ICC Hoses and Flexible Tubes	Language English	Lay Line Style Ink Jet	Minimum Bend Radius 1	Minimum Bend Radius 1	Minimum Working Temperature -40	Net Pack Quantity Units FT	NMFC 70	Product Width 0.25	Qualified Hose Fittings QCAB	Reinforcement Material None	Sub Brand Synflex	Supplier Part Number 4247-0415-0100	Tube Material Polyamide Alloy	Product Weight 0.03 lbs

Product Questions & Answers (1)

Question by: Jimmy S on Aug 17, 2025, 4:57 PM

Got a trailer air brake harness to build, is this the kind of tubing folks use for straight runs and formed pieces?

Answer by: Customer Support on Aug 19, 2025, 6:27 AM

For air brake work, it fits the common use cases like truck and trailer air brake systems, plus auxiliary air systems. It is also called out for formed tubes and for formed and straight air brake harness assemblies.
