Fitting (Perm) 4S

Ask A Question

Description & Features

This carbon steel Perm 4S fitting features a female Metric end and a Line/Hose/Tube end. The fitting is plated with Dura-Kote for superior corrosion resistance, and system engineered to extend hose assembly life. Its innovative design delivers enhanced performance and maximum uptime.

The Aeroquip Fitting (Perm) 4S is SAE J1176 certified. It is suitable for use with -6 hose dash size.

SKU: 4S10DS6

Supplier Part Number (MPN): 4S10DS6

Specifications

Brand
Aeroquip® by Danfoss
a Dimensions
2.24 in
Compatible Hose ID
0.38 in
Connection Size 1
3/8 in
Connection Size 2
5/8 in
Connection Type
Female DKOS Swivel, Hose
Connection Type 1
Hose
Connection Type 2
Female DKOS DIN 24 deg Seat Swivel
Construction Style
Crimp
Cut-Off Factor
1.24 in
Dimension Standards
SAE J1176
Dimensions
2.3 in L x 1.16 in W x 1.22 in H
End Gender 1
Female
End Size 1
10
Finish
Dura-Kote™
Fitting Type
Hose Fitting
For Use With
H430, H430R, H525H, H471, H810L, H600, H464 and H850 Series Hoses
Hex Size
1.06 in
Hose Dash Size
06
Inside Diameter
1.26 in
Manufacturing Cage Code
VAN WERT OH - 0X660
Material
Steel
Material Construction
Carbon Steel
nmfc
50
Seal Material
NBR
Segment Code
C
Series
4S Series
Thread Sealant
Without Thread Sealant
Thread Size
M22x1.5

Product Questions & Answers (1)

Question by: Wayne W on Dec 30, 2025, 7:15 PM
Is this fitting resistant to corrosion?
Answer by: Customer Support on Dec 31, 2025, 9:40 PM
Yes, the Dura-Kote plating provides superior corrosion resistance. That's a big help in extending the life of the fitting, especially in harsh environments.
