The Split Flange Code 61 22.5 from Danfoss Power Solutions (ii Llc Aeroquip) is engineered to meet the highest standards of performance and reliability. Designed for industrial applications this fitting features Dura-Kote plating providing superior corrosion resistance under the most demanding conditions.
Constructed from high-quality carbon steel it ensures extended service life and durability making it an ideal choice for complex hose assemblies. The innovative design enhances performance and maximizes uptime ensuring your equipment operates smoothly and efficiently.
Certified to SAE J1176 standards this fitting is system-engineered to extend hose assembly life reducing maintenance requirements and downtime. With a drop dimension of 0.9300 it fits seamlessly into various configurations offering versatility and adaptability for different industrial needs.
Certifications: SAE J1176
Supplier Part Number: 4S32FLD32
Loading related products…
Specifications
Alternate Part Numbers
Alternate Part NumberMI-08051667, Alternate Part Number MINO-00015X01288, Alternate Part Number MINO-00925F18041
Certifications
SAE J1176
Drop Dimension
0.93
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
End Type 1
Flanged
End Type 2
Line/Hose/Tube
Features
Dura-Kote plating for superior corrosion resistance|Innovative design to deliver performance and maximum uptime|System engineered to extend hose assembly life
Hose Dash Size
-32
ICC
Hose Fittings
Item Type
Fitting Assembly
Language
English
Net Pack Quantity Units
EA
NMFC
50
Product Material
Carbon Steel
Product Width
3.39
Sub Brand
None
Supplier Part Number
4S32FLD32
Product Weight
7.19 lbs
Product Questions & Answers (2)
Question by: Judy M on Jun 7, 2025, 11:24 AM
What size hose does this flange fit? I'm workin' with some pretty thick stuff here.
Answer by: Customer Support on Jun 8, 2025, 1:16 PM
This split flange is made to work with a -32 hose dash size, which should help you get the right fit for those larger diameter hoses.
Question by: Roger M on Dec 16, 2025, 12:50 PM
what's the drop dimension on this flange, and does the 22.5 degree angle make fitment tricky in tighter installs?
Answer by: Customer Support on Dec 17, 2025, 3:06 PM
The drop dimension comes in at 0.9300, and the 22.5 degree angle is actually there to help in situations where a straight or 90 degree fitting just won't clear surrounding components. Tight routing gets a lot easier when you've got that offset working in your favor rather than fighting a straight shot into a crowded port area.
