main product photo

Fitting (Perm) Thermo JIC Bulkhead With Nut

Ask A Question

Description & Features

Designed for bulkhead installations requiring a secure, permanent termination, this carbon steel fitting carries a female JIC 37° end on a -6 dash size (9/16 in.) connection and includes the mating nut for a complete, ready-to-install assembly. The Fitting (Perm) Thermo JIC Bulkhead With Nut is part of the Aeroquip crimp fitting lineup, built to work with thermoplastic hose assemblies in demanding hydraulic circuits.

Dura-Kote plating provides strong corrosion resistance suited to harsh service environments. The fitting's design supports extended hose assembly service life and is system-engineered for consistent performance and reduced downtime across hydraulic applications where a bulkhead pass-through connection is required.

SKU: 4TA6CB6

Supplier Part Number (MPN): 4TA6CB6

Specifications

Brand
Synflex Optimum by Danfoss
a Dimensions
2.85 in
Compatible Hose ID
3/8 in
Connection Size 1
3/8 in
Connection Size 2
3/8 in
Connection Type
Female JIC Swivel, Hose
Connection Type 1
Hose
Connection Type 2
Female SAE 37 deg JIC Flare Swivel
Construction Style
Crimp
Cut-Off Factor
1.86 in
Dimensions
2.85 in L
End Connection Torque
18 to 20 lb-ft
End Gender 1
Female
End Size 1
9/16 in
Finish
Dura-Kote™
Fitting Type
Hose Fitting
For Use With
3TR18CT, 3TR8, 3TR8N, 3TR7 and 3TR7N Series Hoses
Hex Size
0.81 in
Hose Dash Size
06
Inside Diameter
0.26 in
Material
Steel
Material Construction
Carbon Steel
Series
4T Series
Thread Sealant
Without Thread Sealant
Thread Size
9/16-18
Thread Type
UNF

Product Questions & Answers (1)

Question by: Sheila T on Aug 26, 2025, 6:17 AM
Hey, will this fitting hold up if it's out in the weather a lot? I'm using it on some equipment that sits outside.
Answer by: Customer Support on Aug 28, 2025, 6:22 AM
Dura-Kote plating gives this fitting strong corrosion resistance, so it should handle outdoor conditions pretty well. It's made to last in harsh environments.
