5000 Series DIN 43650 / ISO 4400 Solenoid Connector, Strain Relief Style, Translucent, 0.315 to 0.394 Inch Cable Diameter

Description & Features

The 5000 Series DIN 43650 / ISO 4400 Solenoid Connector, Strain Relief Style, Translucent, 0.315 to 0.394 Inch Cable Diameter delivers robust performance and reliability. This connector from Canfield Industries Inc ensures a secure and dust-tight connection with its Nema Type 4 and IP65 rating, providing effective protection against water and dust ingress.

Featuring a nitrile seal material, the connector supports a temperature range from -13deg;F to 194deg;F, while the optional silicone gasket expands this range to -40deg;F to 257deg;F. The 2+ground wiring configuration and a maximum current rating of 10 amps make it suitable for a variety of electrical applications.

The strain relief style translucent casing highlights its durability and visibility. It accommodates cable diameters from 0.315 to 0.394 inches, with a maximum cable diameter of 0.41 inches. Additionally, the connector can handle a voltage rating of up to 300 VDC / 250 VAC at 50/60 Hz.

For added flexibility, the cable outlet can be assembled in 90deg; increments. Indicator lights and pre-wired options enhance its versatility, making it available in black, gray, or translucent for models with lights.

MPN: C1FK20

Supplier Part Number: 5103-1090000

Specifications

Color Translucent	Diameter (in) 0.315 to 0.394	Brand Canfield Industries Inc	Brand Canfield Industries	Pack Size 1.00	UOM EA	Ground Down	Lights 6-48 VAC/VDC 50/60 Hz	Seal Material Nitrile	Supplier Part Number 5103-1090000	Product Weight 0.05 lbs	Alternate Part Numbers Alternate Part Number C1FK20

Similar Products

Model Number	Ground	Lights	Seal Material	Wiring	Color	Diameter (in)	Price	Action
5100-10900 5000 Series DIN 43650 Connector	Down	--	Nitrile	2+Ground	Black	0.236 to 0.315
5103-1090000 5000 Series DIN 43650 Connector	Down	6-48 VAC/VDC 50/60 Hz	Nitrile	2+Ground	Translucent	0.315 to 0.394

Product Questions & Answers (4)

Question by: Wayne H on Jul 16, 2025, 12:02 PM

got a cord that measures right around 3/8 inch, will this strain relief actually clamp down on it?

Answer by: Customer Support on Jul 18, 2025, 6:52 AM

Cable fit is based on diameter, and this strain relief style is meant for cable in the 0.315 to 0.394 inch range, with a listed maximum of 0.41 inch. A 3/8 inch cable is 0.375 inch, so it lands inside the specified range.

Question by: Brent G on Jun 26, 2025, 8:18 PM

does this connector work with cables on the thicker end, like close to 0.4 inch diameter? got some heavier gauge wiring on a valve bank and need something that'll clamp down proper

Answer by: Customer Support on Jun 28, 2025, 7:31 PM

Cable diameters from 0.315 to 0.394 inches fall within the rated range for this connector, so heavier cables in that window should seat and seal correctly with the strain relief. Just keep in mind the maximum cable diameter for the broader 5000 Series is 0.41 inches, so anything pushing past that would be outside what the strain relief is built to handle.

Question by: Carl P on Jul 1, 2025, 12:45 PM

got a pretty thick cord on my coil, what cable size will this translucent DIN plug actually take?

Answer by: Customer Support on Jul 3, 2025, 6:42 AM

The strain relief is meant for cable diameters from 0.315 to 0.394 inches, and the maximum cable diameter called out is 0.41 inches.

Question by: Glen H on Nov 2, 2025, 7:39 PM

what's the temp range on this connector if I'm running it somewhere that gets real cold in the winter and hot as all get out in the summer?

Answer by: Customer Support on Nov 4, 2025, 10:59 AM

With the standard nitrile gasket it'll handle anywhere from -13°F up to 194°F. If your environment pushes past those limits in either direction, there's an optional silicone gasket that stretches the range down to -40°F and up to 257°F. So even in pretty extreme conditions, you've got a path forward without swapping out the whole connector.
