Din X Mmetric Es Seal Complete

Description & Features

Constructed from steel in a straight configuration, this Adaptall fitting connects DIN tube and metric ends using M18 x 1.5 threads on both sides. The DIN tube side carries an L12 designation, while the metric side is sized at 18mm, making it a practical adapter where these two connection standards meet within a hydraulic circuit.

The Din X Metric Es Seal Complete measures 31.5mm along its primary length (L1), with secondary lengths of 12.5mm (L2) and 12mm (L3), and a channel width of 24mm. The male-to-male orientation suits inline installations where both mating ports share the same thread form but differ in tube standard.

SKU: 5068L-12-18C

Supplier Part Number (MPN): 5068L-12-18C

Specifications

CH Width 24mm	L1 Length 31.5mm	L2 Length 12.5mm	L3 Length 12mm	Adaptall Material Steel	Adaptall Shape Straight	Side 1 Callout M18 X 1.5	Side 1 Gender M	Side 1 Size L12	Side 1 Type Din Tube	Side 2 Callout M18 X 1.5	Side 2 Gender M	Side 2 Size 18mm	Side 2 Type Metric	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 5068L-12-18C	Product Weight 0.12 lbs

Product Questions & Answers (2)

Question by: Bonnie G on Jan 7, 2026, 8:51 AM

trying to hook a DIN tube end to a metric port, is this the kind of adapter that’ll do it

Answer by: Customer Support on Jan 8, 2026, 3:31 PM

Built for that crossover, it’s a straight steel male to male adapter with M18 x 1.5 threads on both ends. Side 1 is the DIN tube end with an L12 designation, and side 2 is the metric end sized at 18 mm, so it’s meant for inline spots where the thread is the same but the tube standard differs.

Question by: Kirk P on Oct 20, 2025, 3:58 PM

What kinda steel is this fitting made from? Just wanna make sure it'll hold up.

Answer by: Customer Support on Oct 21, 2025, 8:21 PM

The Adaptall fitting is constructed from steel, ensuring it can withstand typical hydraulic pressures and provide a reliable connection.
