Ldin Banjo X Metric-Es Seals

Description & Features

Constructed from steel, this 90° elbow adapter connects an L15 DIN tube fitting (M22 x 1.5 male) to an 18mm metric port (M18 x 1.5 male), making it a practical solution for routing hydraulic lines at right angles where DIN and metric systems meet. The banjo-style configuration on the DIN side allows for compact, low-profile connections in confined spaces.

The Ldin Banjo X Metric-Es Seals is an Adaptall fitting designed for cross-standard hydraulic assemblies that require a reliable, leak-resistant connection between DIN tube and metric end configurations. It is suited for use in hydraulic circuits where space constraints or directional routing favor an elbow over a straight fitting.

SKU: 5069BJL-15-18

Supplier Part Number (MPN): 5069BJL-15-18

Specifications

Adaptall Material Steel	Adaptall Shape 90° Elbow	Side 1 Callout M22 X 1.5	Side 1 Gender M	Side 1 Size L15	Side 1 Type Din Tube	Side 2 Callout M18 X 1.5	Side 2 Gender M	Side 2 Size 18mm	Side 2 Type Metric	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 5069BJL-15-18	Product Weight 0.54 lbs

Product Questions & Answers (1)

Question by: Sherry M on Jan 28, 2026, 7:24 AM

Will this here fitting work to connect a DIN tube to a metric port at a right angle?

Answer by: Customer Support on Jan 29, 2026, 8:48 AM

Yes sir, that's exactly what it's designed for – connecting a DIN tube fitting to a metric port at a 90-degree angle.
