Designed for on-highway hydraulic wet lines, dump vehicles, refuse vehicles, and bulk liquid transfer applications, these carbon steel quick disconnect couplings deliver reliable, tool-free connection and disconnection in demanding fluid transfer environments. The Danfoss / Eaton Couplings - Code Cp belong to the Hansen 5100 Series and are rated for flow up to 100 gallons per minute, with performance that exceeds ISO 16028 operating pressure requirements.
Buna-N seals provide broad fluid compatibility, and the two-way valve design supports controlled flow in hydraulic circuits. A minimum working temperature of -40°F makes these couplings well suited for cold-weather service. The flange-style configuration and robust carbon steel construction contribute to long service life in high-cycle industrial use.
SKU: 5100-22-24S
Supplier Part Number (MPN): 5100-22-24S
|
Alternate Part Numbers
MINO-00925X11312
|
Application
Hydraulics and fluid transfer, On-highway hydraulic wet lines, Dump and refuse vehicles, Bulk liquid transfer
|
Brand
Danfoss Power Solutions (II LLC Aeroquip)
|
Brand
Aeroquip
|
Pack Size
1.00
|
UOM
EA
|
Features
Quick connect and disconnect|No need for special tools|Exceeds ISO 16028 operating pressures
|
Flow Rate1
100 gallons per minute
|
ICC
Quick Disconnect Couplings
|
Item Type
Component
|
Language
English
|
Minimum Working Temperature
-40
|
Net Pack Quantity Units
EA
|
NMFC
50
|
Product Material
Carbon Steel
|
Product Width
3.88
|
Seal Material
Buna-N
|
Sub Brand
Hansen
|
Supplier Part Number
5100-22-24S
|
Valve Type
2 way
|
Product Weight
0.15 lbs
|
