08MP-08MP HEX NIPPLE

Ask A Question

Description & Features

Constructed from straight stainless steel, this reducer hex nipple connects a 1/2-14 Male NPTF thread on one end to a 3/8-18 Male NPTF thread on the other, making it well suited for hydraulic and industrial fluid systems that require a threaded size transition. Both threads conform to SAE J476, and the fitting is rated to 6,000 PSI dynamic pressure, appropriate for demanding service conditions.

The 08MP-06MP Hex Nipple from Brennan Industries features a hex body for wrench engagement during installation and an overall length of 1.700 mm. Stainless steel construction provides resistance to corrosion in harsh or moisture-exposed environments. California residents should note that this product is subject to Prop 65 requirements.

SKU: 5404-08-06-SS

Supplier Part Number (MPN): 5404-08-06-SS

Alternate Part Numbers: AHN-1/2X3/8

Specifications

Brand
BRENNAN
Connection Size 1
1/2 in
Connection Size 2
3/8 in
Connection Type
MNPT
Connection Type 1
Male SAE 30 deg NPTF
Connection Type 2
Male SAE 30 deg NPTF
Cubic Inch Space L x W x H Dimensions
1.302 cu-in
Dimension Standards
SAE J476, SAE J514
Dimensions
1.7 in L
Fitting Type
Nipple
Hex Size
7/8 in
Material
Stainless Steel
Material Construction
316/316L Stainless Steel
Series
5404 Series
Thread 2 Drill Dimensions
0.406 in
Thread B1 Drill Dimensions
0.531 in
Thread Size
1/2-14 x 3/8-18

Product Questions & Answers (1)

Question by: Rick T on Jan 23, 2026, 6:23 AM
Can you tell me what kind of threads this has?
Answer by: Customer Support on Jan 25, 2026, 6:03 AM
This fitting has a 1/2-14 Male NPTF thread on one end and a 3/8-18 Male NPTF thread on the other.
