08MP-08MP 90 DEG ELB BRASS

Ask A Question

Description & Features

A 90-degree male-to-male elbow fitting in straight brass construction, the 08MP-08MP 90 Deg Elb Brass routes flow at a right angle between two 1/2-14 Male NPTF threaded connections. Both ports conform to SAE J476, making this fitting well suited for use in hydraulic and fluid power assemblies where a dryseal thread form is required.

Machined from straight brass stock, this Brennan Industries Series 5500 fitting offers reliable sealing performance in applications where corrosion resistance and compatibility with a range of hydraulic fluids are priorities. The matching thread specification on both ends simplifies installation in symmetrical or inline configurations requiring a directional change.

SKU: 5500-08-08-B

Supplier Part Number (MPN): 5500-08-08-B

Specifications

Brand
BRENNAN
Connection Size 1
1/2 in
Connection Size 2
1/2 in
Connection Type
MNPT
Connection Type 1
Male SAE 30 deg NPTF
Connection Type 2
Male SAE 30 deg NPTF
Cubic Inch Space L x W x H Dimensions
3.184 cu-in
Dimension Standards
SAE J476, SAE J514
Dimensions
1.47 in L
Fitting Type
90 deg Elbow
Hex Size
7/8 in
l Dimensions
1.47 in
Material
Brass
Material Construction
UNS CA377 Brass
Series
5500-FG Series
Thread 2 Drill Dimensions
0.531 in
Thread B1 Drill Dimensions
0.531 in
Thread Size
1/2-14

Product Questions & Answers (1)

Question by: Duane E on Oct 31, 2025, 8:44 AM
Will this brass elbow hold up okay with regular hydraulic fluid?
Answer by: Customer Support on Nov 1, 2025, 4:21 PM
Machined from straight brass stock, this fitting offers reliable sealing performance when used with a range of hydraulic fluids, so you shouldn't have any problems with standard hydraulic fluid.
