main product photo

04FP-04FP-04MP BRANCH TEE BRASS

Ask A Question

Description & Features

Machined from straight brass stock, this 1/4 in. branch tee provides a reliable three-way connection for splitting or combining fluid lines in hydraulic and industrial systems. The 04FP-04FP-04MP Branch Tee Brass features two female NPTF ports and one male NPTF port, all sized at 1/4-18 and conforming to SAE J476 specifications, ensuring leak-resistant, dry-seal thread engagement without additional sealants.

With a centerline length of 0.880 in. on both branch ports and an overall length of 1.090 in., this compact fitting is well suited for tight-clearance installations. Brass construction offers good corrosion resistance and compatibility with a wide range of hydraulic fluids and industrial media. Manufactured by Brennan Industries under their Series 5604 line. California residents should note that this product carries a Proposition 65 warning.

SKU: 5604-04-04-04-B

Supplier Part Number (MPN): 5604-04-04-04-B

Specifications

Brand
BRENNAN
Connection Size 1
1/4 in
Connection Size 2
1/4 in
Connection Type
FNPT, MNPT
Connection Type 1
Female SAE NPTF
Connection Type 2
Female SAE NPTF
Connection Type 3
Male SAE 30 deg NPTF
Dimension Standards
SAE J476, SAE J514
Dimensions
1.76 in L
Fitting Type
Tee
Hex Size
3/4 in
l Dimensions
1.09 in
Material
Brass
Material Construction
UNS CA377 Brass
Series
5604-FG Series
Thread 2 Drill Dimensions
0.281 in
Thread 3 Drill Dimensions
0.281 in
Thread B1 Drill Dimensions
0.281 in
Thread Size
1/4-18

Similar Products

Model Number Connection Size 1 Connection Size 2 Connection Size 3 Price Action
PLUMB 3/8 NPT M BRANCH TEE BRASS

3600-06-06-06

3/8 in

3/8 in

3/8 in

Product Questions & Answers (1)

Question by: Harold C on Aug 26, 2025, 9:15 AM
What size threads does this tee use?
Answer by: Customer Support on Aug 27, 2025, 2:35 PM
It uses 1/4-18 threads on all three ports, so it should fit standard 1/4 inch NPT fittings.
