PVH098R01AJ30A250000001003AB010A

Ask A Question

Description & Features

The Danfoss PVH098R01AJ30A250000001003AB010A is a highly durable open circuit piston pump designed for demanding industrial applications. Engineered with a robust construction and torque-limiting capabilities, this pump is ideal for use in mining machinery, injection molding machines, and oil and gas equipment. Its durable construction ensures long-lasting performance, even in the toughest environments.

Featuring a Q250 valve plate, this pump is part of the trusted Vickers sub-brand under Danfoss Power Solutions. With a product width of 9.17 inches, it is designed to fit seamlessly into a variety of heavy-duty systems, including conveyor lines and metal cutting equipment. Whether in primary metals or metal forming machines, this pump delivers consistent, reliable performance.

SKU: 611AK00200A

Supplier Part Number (MPN): 611AK00200A

Specifications

Brand
Vickers by Danfoss
Auxiliary Mount Output Shaft
No Auxiliary Mounting or Output Shaft
Control Type
Pressure Compensator
Design Code
1
Dimensions
14.94 in L x 9.17 in W x 10.77 in H
Drain Port Size Location
7/8-14 UNF-2B SAE O-ring Port - Bottom (Top Plugged)
Drive Shaft Type
Keyed
Flow Compensation Unload Valve
No Flow Compensation Setting Or Unload Valve Standby
Front Mounting Input Shaft
SAE J744-127-4 4-Bolt C with 31.8 mm Dia Straight Keyed Shaft (Key Included), 56 mm Shaft Extension
Housing Color
Blue
Housing Material
Iron
Inlet Type
Code 61 Flange
Main Ports Size Location
Side Ports, Suction: 2-1/2 in SAE 4-Bolt Split Flange Port Standard Pressure Series (Code 61) with 1/2-13 UNC-2B Threads, Pressure- 1 in SAE 4-Bolt Split Flange Port Standard Pressure Series (Code 61) with 3/8-16 UNC-2B Threads
Maximum Displacement Option
Standard Displacement
Mounting Type
SAE C 4-Bolt Flange
nmfc
125820
Outlet Type
Code 61 Flange
Pressure Compensator Setting
246 to 254
Rotation Direction
Clockwise
Seal Material
Nitrile
Series
PVH Series
Special Features
Q250 Valve Plate

Product Questions & Answers (1)

Question by: Rick H on Apr 18, 2025, 8:00 PM
What's the width on this pump, if I'm trying to squeeze it in somewhere?
Answer by: Customer Support on Apr 20, 2025, 8:15 AM
At its widest point, this Danfoss PVH series pump measures 9.17 inches.
