BRENNAN 12 F-JIC SWIVEL X 12 M-ORB SS

Description & Features

Constructed from straight stainless steel, the Brennan 12 F-JIC Swivel x 12 M-ORB SS is a straight hydraulic adapter designed for reliable thread-to-thread connections in demanding industrial environments. One end features a 1-1/16-12 Male SAE O-Ring Boss thread, while the other provides a 1-1/16-12 Female JIC Swivel with a 37-degree flare, both conforming to SAE J514. The swivel end allows for rotational positioning during installation, reducing stress on connected lines.

The stainless steel construction makes this fitting well-suited for applications where corrosion resistance is a priority. An NBR O-ring seal is included at the O-Ring Boss end, providing a positive, leak-resistant connection. With an overall length of 2.140 inches and a hex size of 1.250 inches, it fits standard wrenching in tight installations. This fitting belongs to Brennan Industries' 6402-O series.

SKU: 6402-12-12-O-SS

Supplier Part Number (MPN): 6402-12-12-O-SS

Alternate Part Numbers: 6402-12-12-SS-TOM

Specifications

Brand Brennan Industries Inc	Brand Brennan Industries	Pack Size 1.00	UOM EA	Supplier Part Number 6402-12-12-O-SS	Product Weight 0.40 lbs

Product Questions & Answers (1)

Question by: Glen L on Jul 14, 2025, 6:43 PM

Will this here fitting work to hook up a JIC line to an ORB port?

Answer by: Customer Support on Jul 16, 2025, 6:23 AM

that's precisely what this adapter is for. It's got a Female JIC Swivel on one side and a Male O-Ring Boss on the other, both sized for 1-1/16-12 threads.
