Split Flange Code 61

Description & Features

Crafted from durable carbon steel, the Eaton Aeroquip Split Flange Code 61 is designed for high-performance hydraulic applications. This fitting assembly features a flanged end type on one side and a line/hose/tube connection on the other, ensuring a secure fit in your hydraulic systems. The Dura-Kote plating offers superior corrosion resistance, prolonging the life of your hose assemblies. Engineered to meet SAE J1176 standards, this fitting is ideal for maintaining peak performance and maximizing uptime in demanding environments.

Designed for use with 6-wire spiral hoses, the innovative design of this fitting assembly helps extend hose assembly life. With a hose dash size of -24 and a product width of 2.96 inches, it fits seamlessly into your existing setup. The Eaton Aeroquip brand is synonymous with quality and reliability, making this fitting a trusted choice among industrial professionals.

SKU: 6S32FL24

Supplier Part Number (MPN): 6S32FL24

Specifications

Brand Aeroquip® by Danfoss	a Dimensions 6.88 in	Compatible Hose ID 1-1/2 in	Connection Size 1 1-1/2 in	Connection Size 2 2 in	Connection Type Flanged, Hose	Connection Type 1 Hose	Connection Type 2 SAE Code 61 Flange	Construction Style Crimp	Cut-Off Factor 3.81 in	Dimension Standards SAE J1176	Dimensions 6.88 in L x 2.96 in W x 2.96 in H	End Size 1 32	Finish Dura-Kote™	Fitting Type Hose Fitting	For Use With FC500, F273B, EC810, EC600, FC606, GH466, EC850 and EC420 Series Hoses	Hose Dash Size 24	Inside Diameter 1.22 in	Material Steel	Material Construction Carbon Steel	nmfc 50	Seal Material EPDM	Segment Code C	Series 6S Series	Thread Sealant Without Thread Sealant

Product Questions & Answers (1)

Question by: Randy P on Oct 29, 2025, 1:02 PM

does this fitting work with 6-wire spiral hose or is it only for certain hose types

Answer by: Customer Support on Oct 31, 2025, 6:59 AM

Built specifically for 6-wire spiral hose assemblies, this is an Eaton Aeroquip 6S Series crimp fitting. The -24 dash size tells you the hose bore it's sized for, so as long as your spiral hose matches that sizing, you're in the right ballpark for a proper crimp connection.
