70-100 Series Bronze Ball Valve, 3 NPT Ports

Description & Features

Rated for 600 psig WOG (cold non-shock) and 150 psig saturated steam, this full-featured bronze ball valve is built for dependable shut-off in demanding industrial fluid control applications. The 70-100 Series Bronze Ball Valve features a B584-C84400 bronze body, a chromium-plated B16 ball, and RPTFE seats and stem packing for reliable sealing performance across a wide service range. Vacuum service to 29 in./Hg is supported.

The blow-out proof stem design and adjustable packing gland allow for field maintenance without full valve replacement. A zinc-plated steel lever with vinyl cover provides secure manual actuation. Port configuration is 3 NPT with a 2.5-inch orifice diameter and a Cv factor of 370. The PTFE body seal and B584-C84400 retainer are standard on this size. Seal kit 70-009-01 is available separately for service needs.

SKU: 70-100-01

Supplier Part Number (MPN): 7010001

Alternate Part Numbers: C1EN77

Specifications

CV Factor 370.00	Brand Conbraco Ind Inc	Brand Conbraco Ind	Pack Size 1.00	UOM EA	Orifice Diameter 2.50	Ports 3 NPT	Ports 3 NPT	Seal Kit 70-009-01	Supplier Part Number 7010001	Alternate Part Numbers Alternate Part Number C1EN77	Product Weight 18.60 lbs

Similar Products

Model Number	Ports	Orifice Diameter	CV Factor	Seal Kit
70-100-01 70-100 Series Bronze Ball Valve	3 NPT	2.5	370.0000	70-009-01
70-101-01 70-100 Series Bronze Ball Valve	1/4 NPT	0.37	8.4000	70-002-01
70-103-01 70-100 Series Bronze Ball Valve	1/2 NPT	0.5	15.0000	70-003-01
70-104-01 70-100 Series Bronze Ball Valve	3/4 NPT	0.68	30.0000	70-004-01
70-105-01 70-100 Series Bronze Ball Valve	1 NPT	0.87	43.0000	70-005-01

Product Questions & Answers (2)

Question by: Chad H on Mar 30, 2025, 12:00 PM

what's the pressure rating on this ball valve, and is it any good for steam lines?

Answer by: Customer Support on Apr 1, 2025, 6:41 AM

At cold, non-shock conditions it's rated for 600 psig WOG, which covers a wide range of general hydraulic and fluid service applications. For saturated steam specifically, the rating drops to 150 psig. Worth knowing that pressure capacity does decrease further at elevated temperatures, so if your steam system runs hot, that's something to factor in before you commit to this one.

Question by: Kent B on Apr 10, 2025, 7:48 AM

What size threads does this valve have?

Answer by: Customer Support on Apr 12, 2025, 6:45 AM

It comes with 3 NPT ports.
