Danfoss / Eaton Piston Motor

Description & Features

Designed for medium-duty mobile equipment, this fixed axial-piston unit from Danfoss Power Solutions delivers a torque rating of 183.36 Nm and a flow rate of 142.43 litres per minute, making it well suited to demanding duty cycles in the field.

The Danfoss / Eaton Piston Motor supports a wide range of equipment types, including harvesters, sprayers, log skidders, lift trucks, scissor lifts, fan drives, lawn tractors, and bark removers. A through-drive option adds flexibility for multi-function configurations, and the design supports straightforward servicing in the field.

This motor includes a speed sensor magnetic pickup with a 9-pulse output and a 3-pin Weather Pack connector fitted with a 127 mm [5.0 in] lead wire, a factory-integrated feature useful for closed-loop control and monitoring applications.

SKU: 74315-DAW

Supplier Part Number (MPN): 74315-DAW

Specifications

Alternate Part Numbers Alternate Part Number MINO-00287X00073	Application Harvesters, Sprayers, Log Skidders, Fan Drives, Lawn Tractors, Lift Trucks, Scissor Lifts, Bark Removers	Brand Danfoss – Hydraulics	Brand Danfoss Power Solutions	Pack Size 1.00	UOM EA	Features Advanced design features\|Through drive option\|Easy to configure and service	Flow Rate1 142.43 litre per minute	ICC HS MP Fixed Axial-Piston Motors	Language English	Product Width 6.88	Special Features Speed Sensor Magnetic Pickup (9 Pulse), 3 Pin Weather Pack Connector With 127 [5.0] Lead Wire	Sub Brand None	Supplier Part Number 74315-DAW	Torque Rating 183.36 newton metre	Torque Rating 183.36 newton metre	Product Weight 20.00 lbs

Product Questions & Answers (1)

Question by: Troy F on Sep 18, 2025, 5:07 PM

I'm wondering if this motor is okay to use on a log skidder?

Answer by: Customer Support on Sep 20, 2025, 1:24 PM

Yes, it's definitely suitable for log skidders. It's also designed for use in harvesters, sprayers, lawn tractors, lift trucks, scissor lifts and bark removers.
