800201004

Description & Features

Designed for use in high-pressure hydraulic circuits, the 800201004 is a male external fitting with a 3/8 NPT thread configuration. The male (external) thread form allows for direct connection into female-ported components, manifolds, and hydraulic assemblies where a 3/8 NPT interface is specified.

With NPT being a tapered thread standard widely used in fluid power and industrial hydraulic systems, this fitting provides a reliable mechanical seal when properly installed. The external thread design suits applications where the fitting seats into a receiving port, making it a practical choice for a range of industrial hydraulic connections at this thread size.

SKU: 800201004

Supplier Part Number (MPN): 800201004

Specifications

Brand Stucchi®	Connection Size 1 3/8 in	Connection Size 2 3/8 in	Connection Type Female, MNPT	Connection Type 1 Female	Connection Type 2 Male NPT	Dimension Standards ANSI/ASME B1.20.1	Dimensions 1.38 in Dia x 2.84 in L	Finish Zinc-Plated	Fitting Type Coupler	Hex Size 0.94 in	Material Steel	Material Construction CR3 Carbon Steel	Series IV-HP Series

Product Questions & Answers (1)

Question by: Harvey W on Jan 6, 2026, 8:55 PM

Is this fitting somethin' I can screw right into a hydraulic pump with a 3/8 NPT port?

Answer by: Customer Support on Jan 8, 2026, 8:38 AM

Yes, this fitting has a 3/8 NPT male thread, so it should screw directly into any hydraulic component or manifold with a matching 3/8 NPT female port. Just make sure to use sealant.
