Brass Female Bsp Coupling

Description & Features

This straight brass coupling features female BSPP threads on both ends, each with a 3/4" size and G 3/4 - 14 callout. The Adaptall fitting has a 32mm wrench flat width and an overall length of 32mm.

The Brass Female BSP Coupling provides a reliable connection in hydraulic systems.

SKU: 8043-12-12

Supplier Part Number (MPN): 8043-12-12

Specifications

Connection Size 1 3/4 in	Connection Size 2 3/4 in	Connection Type Female BSP	Connection Type 1 Female BSP	Connection Type 2 Female BSP	Dimension Standards BS 5200	Dimensions 32 mm L	Finish Nickel-Plated	Fitting Type Adapter	Hex Size 32 mm	Material Brass	Material Construction Brass	Series 8043 Series	Thread Size 3/4-14

Product Questions & Answers (2)

Question by: Bobby G on Nov 30, 2025, 5:26 PM

both ends on this coupling are female BSPP, right? just want to make sure before i order it for a 3/4 inch line swap

Answer by: Customer Support on Dec 2, 2025, 4:17 PM

Correct on both counts. Each end carries a female BSPP thread with a G 3/4 - 14 callout, so you're working with 3/4 inch connections on both sides. It's a straight fitting, no offsets or angles, which keeps the swap clean if your existing line runs in a direct path.

Question by: Tony T on Jun 23, 2025, 9:53 AM

Will this fitting hold up okay outside? I need to run some hydraulic lines to a log splitter that sits out in the weather.

Answer by: Customer Support on Jun 24, 2025, 7:42 PM

Brass is generally pretty resistant to corrosion, so this coupling should work fine for outdoor use on your log splitter.
