806504004

Description & Features

Designed for SAE hydraulic connections, this male fitting is configured for 3/4 SAE ported applications. The 806504004 carries the designation F. VEP 13P 3/4 SAE, indicating its thread form and port sizing for use in hydraulic circuit assembly and component interfacing where a standardized SAE male connection is required.

With a male configuration, this fitting is suited for direct engagement with corresponding female SAE ports in hydraulic systems. Limited additional specification data is available for this part; refer to the full specification table and supplier documentation for dimensional and pressure details.

SKU: 806504004

Supplier Part Number (MPN): 806504004

Specifications

Brand Stucchi®	Connection Size 1 1/2 in	Connection Size 2 3/4 in	Connection Type Female, Female SAE	Connection Type 1 Female	Connection Type 2 Female SAE	Dimension Standards SAE J1926-1	Dimensions 1.42 in Dia x 3.34 in L	Finish Zinc-Plated	Fitting Type Coupler	Hex Size 1.42 in	Material Steel	Material Construction CR3 Carbon Steel	Series VEP-P Series	Thread Size M40x3

Product Questions & Answers (1)

Question by: Lyle F on Nov 16, 2025, 12:54 PM

Reckon this fitting'll work with my setup? I got SAE ports and need a 3/4 size.

Answer by: Customer Support on Nov 17, 2025, 7:54 PM

This male fitting is indeed designed for SAE hydraulic connections, specifically for 3/4 SAE ported applications, so it should be a good match for your needs.
