VICKERS DGMDC 5 Y AK 30

Description & Features

Designed for demanding industrial hydraulic circuits, the Vickers DGMDC 5 Y AK 30 is a SystemStak directional control valve rated for flow up to 120 litres per minute. Its stackable valve architecture reduces installation complexity by eliminating the need for external interconnecting lines, which also removes potential external leakage points from the circuit.

Buna-N seals provide reliable performance across a broad range of hydraulic fluids. Built-in resistance to contamination makes this valve well suited to harsh or sensitive environments. Applicable across a wide range of industries, including machine tool, press, marine/offshore, die casting and foundry, primary metal, paper, turbine control, and test and simulation equipment.

SKU: 867344

Supplier Part Number (MPN): 867344

Specifications

Brand Vickers by Danfoss	Actuator Type Pressure Operated	Body Material Iron	Check Location Line A	Design Series 30 Series	Dimensions 5.43 in L x 2.82 in W x 1.97 in H	Direction of Flow Towards Actuator	Domestic/Import Domestic	Language English	Material Standard ANSI B93.7M-D03	Media Petroleum Oil	Mounting Type Manifold, Subplate	Nominal Size #5	Performance Standard	Port Operated Upon A Cylinder Port	Seal Material FKM	Series DGMDC-5 Series	Valve Mount Type Subplate/Manifold

Product Questions & Answers (1)

Question by: Glen M on Jun 22, 2025, 6:26 AM

What kind of hydraulic fluid can this handle without issues?

Answer by: Customer Support on Jun 23, 2025, 2:08 PM

Buna-N seals make it compatible with a broad range of hydraulic fluids.
