main product photo

Vickers DGMC2 5 AB FW BA FW

Ask A Question

Description & Features

The Vickers DGMC2 5 AB FW BA FW is a stack valve designed to reduce installation costs and eliminate external leakage. Its robust design boosts resistance to contamination, ensuring reliable performance in demanding hydraulic applications.

This Vickers valve is suitable for applications such as die casting, foundry, machine tool, marine, offshore, press, primary metal, paper, test equipment, simulation, and turbine control (wind, steam, and water). It features Buna-N seals and a flow rate of 120 liters per minute. The product width measures 2.82 inches.

SKU: 868858

Supplier Part Number (MPN): 868858

Alternate Part Numbers: C1ZX13, DGMC25ABFWBAFW30

Specifications

Brand
Vickers by Danfoss
Actuator Type
Pressure Operated
Adjustment Type
Screw and Locknut
Body Material
Iron
Design
30 Series
Dimensions
8.46 in L x 2.82 in W x 1.97 in H
External Drain
Without External Drain
Function 1 Pressure Adjustment
60 to 2900 psi
Function 2 Pressure Adjustment
60 to 2900 psi
Media
Petroleum Oil
Nominal Size
#5
Number of Stages
2
P Port Acted Upon
B Cylinder Port
Performance
Standard
Port Drained Into
B Cylinder Port
Port Drained Into Dual
A Cylinder Port
Port Operated Upon
A Cylinder Port
Remote Control Port
Without Remote Control Port
Seal Material
FKM
Series
DGMC-2 Series
Valve Mount Type
Subplate/Manifold

Product Questions & Answers (2)

Question by: Tammy C on May 24, 2025, 9:13 PM
seal material on this valve, is it buna-n?
Answer by: Customer Support on May 26, 2025, 6:59 PM
Buna-N is confirmed as the seal material on the DGMC2-5. That makes it a solid pick for standard hydraulic fluid applications where nitrile rubber holds up well. Just worth keeping in mind if your system runs anything aggressive like phosphate ester fluid, since Buna-N has its limits with certain fluid types.
Question by: Wade C on May 15, 2025, 9:08 PM
Can this valve handle continuous operation in a hydraulic press, or is it more suited for intermittent use?
Answer by: Customer Support on May 17, 2025, 6:05 AM
This Eaton Vickers valve is applicable to presses, among other applications. Its suitability for continuous operation will depend on the specific demands of your hydraulic system including flow rates, pressure, and fluid type but is generally robust.
