AEROQUIP BRASS SLEEVE

Description & Features

This Aeroquip brass sleeve is designed for use with Danfoss / Eaton 900568 Series crimp hose fittings. The sleeve is constructed from durable brass material.

Features include Dura-Kote plating for superior corrosion resistance and an innovative design to deliver performance and maximum uptime, while the system engineered to extend hose assembly life. End 1 female size: 0.277. End 2 female size: 0.336. Product width: 0.43.

SKU: 900568-5B

Supplier Part Number (MPN): 900568-5B

Alternate Part Numbers: C1CA89

Specifications

Brand Aeroquip® by Danfoss	Connection Size 1 5/16 in	Connection Size 2 5/16 in	Connection Type Compression, Hose	Connection Type 1 Hose	Connection Type 2 Compression	Dimensions 0.342 in L x 0.434 in W x 0.434 in H	Fitting Type Sleeve	For Use With 2807 and FC807 Hoses	Hose Dash Size 05	Material Brass	Material Construction Brass	nmfc 50	Series 900568 Series

Similar Products

Model Number	Connection Size 1	Connection Size 2	Hose Dash Size
900568-3B Brass Sleeves For Teflon Hose	3/16 in	3/16 in	03
900568-10B Brass Sleeves For Teflon Hose	5/8 in	5/8 in	10
900568-4B Brass Sleeves For Teflon Hose	1/4 in	1/4 in	04
900568-6B Brass Sleeves For Teflon Hose	3/8 in	3/8 in	06
900568-12B Brass Sleeves For Teflon Hose	3/4 in	3/4 in	12
900568-8B	1/2 in	1/2 in	08
900568-16B	1 in	1 in	16
900568-20B	1-1/4 in	1-1/4 in	20
