Bspp Test Port X 1/8" Bspp

Description & Features

The Adaptall BSPP Test Port X 1/8" BSPP is expertly designed for efficient hydraulic testing and diagnostics. Constructed from durable steel, this tee-shaped adapter ensures robust performance in demanding industrial environments. The test port features a G 1 - 11 male connection on Side 1 and G 1 - 11 and G 1/8 - 28 female connections on Sides 2 and 3, respectively, facilitating seamless integration into your hydraulic systems. With a consistent width of 41mm and a length of 64.4mm, this component is engineered for precision and reliability.

This versatile test port is ideal for applications requiring precise monitoring and maintenance checks. The standard BSPP (British Standard Pipe Parallel) threads ensure compatibility with a wide range of hydraulic equipment, making it a trusted choice for professionals in the field.

SKU: 9015TP-16-16-B02

Supplier Part Number (MPN): 9015TP-16-16-B02

Specifications

CH1 Width 41mm	CH2 Width 41mm	L Length 64.4mm	Adaptall Material Steel	Adaptall Shape Tee	Side 1 Callout G 1 - 11	Side 1 Gender M	Side 1 Size 1"	Side 1 Type Bspp	Side 2 Callout G 1 - 11	Side 2 Gender F	Side 2 Size 1"	Side 2 Type Bspp	Side 3 Callout G 1/8 - 28	Side 3 Gender F	Side 3 Size 1/8"	Side 3 Type BSPP	Brand Adaptall America	Brand Adaptall	Pack Size 1.00	UOM EA	Supplier Part Number 9015TP-16-16-B02	Product Weight 0.73 lbs

Product Questions & Answers (3)

Question by: Merle W on Apr 2, 2026, 1:53 PM

got a 1 inch BSPP line and want to add a gauge point, is this the tee that does that?

Answer by: Customer Support on Apr 4, 2026, 6:55 AM

For adding a test point in-line, this tee gives you a 1 inch BSPP male on Side 1, a 1 inch BSPP female on Side 2, and a 1/8 inch BSPP female test port on Side 3 (G 1/8 - 28). It’s meant for hydraulic testing and diagnostics where you need a small port for monitoring.

Question by: Rex H on Dec 27, 2025, 6:07 PM

What's the width on this test port? Just wanna make sure it'll fit where I need it.

Answer by: Customer Support on Dec 29, 2025, 6:41 AM

The width of this Adaptall BSPP test port is 41mm on both Channel 1 and Channel 2.

Question by: Steve A on Oct 12, 2025, 8:30 PM

what's the thread setup on this thing? trying to figure out if it'll tie into my existing 1" BSPP lines without a bunch of extra fittings

Answer by: Customer Support on Oct 14, 2025, 6:25 AM

Side 1 is a 1" BSPP male connection, and Side 2 is a 1" BSPP female, so it runs inline with your existing 1" BSPP hydraulic connections no problem. Side 3 is the test port itself, which is a 1/8" BSPP female. That's where you'd attach a pressure gauge or diagnostic instrument for monitoring. The tee shape keeps everything in line while giving you that dedicated tap point for testing.
