main product photo

Bspp Countersunk Sealed Plug

Ask A Question

Description & Features

Manufactured in steel, this G 1/4 BSPP male countersunk sealed plug is designed to close off unused ports in hydraulic circuits and fluid power assemblies. The countersunk head profile allows the plug to sit flush or recessed within a port face, making it suited for installations where clearance is limited or a low-profile termination is required.

The Adaptall BSPP Countersunk Sealed Plug measures 17.1mm in length with a 19mm cross-width, offering a compact form factor for tight-space applications. The G 1/4 thread size is commonly used across a range of hydraulic valves, manifolds, and component bodies where BSPP-threaded ports are standard.

SKU: 9028-04

Supplier Part Number (MPN): 9028-04

Specifications

Brand
adapt-all
Connection Size 1
1/4 in
Connection Type
Male BSP
Connection Type 1
Male BSPP
Dimension Standards
BS 5200
Dimensions
17 mm L x 19 mm W
Finish
Zinc-Plated
Fitting Type
Plug
Hex Size
7
Material
Steel
Material Construction
Carbon Steel
Maximum Operating Pressure
5000 psi
Series
9028 Series
Thread Size
1/4-19

Similar Products

Model Number Connection Size 1 Thread Size Hex Size Price Action
Bspp Countersunk Sealed Plug+

9028-02

1/8 in

1/8-28

Bspp Countersunk Sealed Plug

9028-06

3/8 in

3/8-19

9 mm

Bspp Countersunk Sealed Plug

9028-08

1/2 in

1/2-14

12 mm

Bspp Countersunk Sealed Plug

9028-12

3/4 in

3/4-14

14 mm

Bspp Countersunk Sealed Plug

9028-16

1 in

1-11

19 mm

Bspp Countersunk Sealed Plug

9028-20

1-1/4 in

1-1/4-11

Bspp Countersunk Sealed Plug

9028-24

1-1/2 in

1-1/2-11

28 mm

Product Questions & Answers (3)

Question by: Danny R on Jan 1, 2026, 3:52 PM
Got a manifold block with a quarter-inch BSPP port I need to cap off. This plug gonna sit flush with the face or is it gonna stick out past it?
Answer by: Customer Support on Jan 3, 2026, 7:22 AM
That countersunk head profile is exactly what keeps it from protruding. It's built to sit flush or even recessed into the port face, so you won't have anything sticking up past the surface. Real handy when clearance around that port is tight or when another component needs to mount close by.
Question by: Denise B on Dec 10, 2025, 3:00 PM
How deep does this plug sit when it's screwed in? I'm workin' with limited space here.
Answer by: Customer Support on Dec 12, 2025, 6:08 AM
The overall length is 17.1mm, so that's how far it'll extend into the port when fully seated. Keep in mind the countersunk head will sit flush or slightly recessed, giving you a lower profile than a standard plug.
Question by: Roger R on May 30, 2025, 9:08 PM
got a G 1/4 bspP port on a manifold i need to cap off, is this the right kind of plug?
Answer by: Customer Support on Jun 1, 2025, 6:19 AM
For a BSPP threaded port, this plug matches a G 1/4 male thread and is made to close off unused ports in hydraulic circuits, valves, and manifolds that use BSPP ports.
