Female Jic Swivel Tee

Description & Features

This steel tee fitting features female JIC swivel connections on all three ends, each with a 9/16 - 18 UNF thread and 3/8" size.

Use this Female Jic Swivel Tee to connect three 3/8" JIC hoses or tubes at a central point, allowing for flexible routing in hydraulic systems.

SKU: 9555-06-06-06

Supplier Part Number (MPN): 9555-06-06-06

Specifications

Connection Size 1 3/8 in	Connection Size 2 3/8 in	Connection Size 3 3/8 in	Connection Type Female JIC Swivel	Connection Type 1 Female JIC Swivel	Connection Type 2 Female JIC Swivel	Connection Type 3 Female JIC Swivel	Dimension Standards ISO 8434-2, SAE J514	Finish Zinc-Plated	Fitting Type Tee	Material Steel	Material Construction Carbon Steel	Series 9555 Series	Thread Size 9/16-18

Product Questions & Answers (2)

Question by: Ralph W on Mar 7, 2026, 5:09 PM

trying to tie three 3/8 jic lines together, is this the tee with swivel female ends on all sides?

Answer by: Customer Support on Mar 9, 2026, 6:05 AM

Built for exactly that setup, it has three female JIC swivel connections, each sized for 3/8 inch JIC with 9/16-18 UNF threads, so you can bring three 3/8 JIC hoses or tubes into one central tee.

Question by: Marvin E on Apr 1, 2026, 11:52 AM

Will this tee work with standard JIC fittings, or are there any special considerations?

Answer by: Customer Support on Apr 3, 2026, 6:37 AM

This steel tee fitting is specifically designed for use with standard female JIC connections, making it suitable for connecting three 3/8" JIC hoses or tubes. The 9/16 - 18 UNF threads ensure compatibility with commonly available JIC fittings.
