AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.62 Inch ID, Up to 750.00 PSI

Ask A Question

Description & Features

The black AQPreg; elastomer tube features a polyester inner braid, single wire braid reinforcement, and a black polyester textile braided cover. It is suitable for a variety of applications including air, gasoline, fuel, lubricating oils, and coolants.

Operating within a temperature range of -55deg;F to +300deg;F (except air +250deg;F), it ensures durability and reliability across different environments. The hose has a minimum bend radius of 2.75 inches, a hose outer diameter of 1.08 inches, and a vacuum service of 20 inches Hg.

With a maximum operating pressure of 750 PSI and a hose inner diameter of 0.62 inches, this product is designed for heavy-duty performance. The reel quantity ranges from 230 to 300 feet, offering flexibility in various industrial applications. The product complies with FMVSS106 standards for safety and performance in engine and air brake systems.

Supplier Part Number: FC350-12RL

MPN: C1CR79

Specifications

Color
Black
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Hose I.D.
0.62
Hose O.D.
1.08
Maximum Operating Pressure
750
Minimum Bend Radius
2.75
Minimum Bend Radius
2.75
Reel Qty (ft)
230-300
Supplier Part Number
FC350-12RL
Alternate Part Numbers
Alternate Part Number C1CR79, Alternate Part Number FC350-12RL
Product Weight
0.93 lbs

Related Documents

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.19 Inch ID, Up to 2000.00 PSI

FC350-04 AQP Engine & Air Brake Hose

0.19

0.52

2000

0.75

28

500-650

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.31 Inch ID, Up to 1500.00 PSI

FC350-06 AQP Engine & Air Brake Hose

0.31

0.68

1500

1.25

28

320-420

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.41 Inch ID, Up to 1250.00 PSI

FC350-08 AQP Engine & Air Brake Hose

0.41

0.77

1250

1.75

28

450-600

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.50 Inch ID, Up to 1250.00 PSI

FC350-10 AQP Engine & Air Brake Hose

0.5

0.94

1250

2.25

28

310-400

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.62 Inch ID, Up to 750.00 PSI

FC350-12 AQP Engine & Air Brake Hose

0.62

1.08

750

2.75

20

230-300

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 0.88 Inch ID, Up to 400.00 PSI

FC350-16 AQP Engine & Air Brake Hose

0.88

1.23

400

3.5

15

180-240

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 1.12 Inch ID, Up to 300.00 PSI

FC350-20 AQP Engine & Air Brake Hose

1.12

1.5

300

4.5

15

120-160

AQP Engine & Air Brake Black Polyester Braid Hose, FMVSS106, 1.38 Inch ID, Up to 250.00 PSI

FC350-24 AQP Engine & Air Brake Hose

1.38

1.75

250

5.5

11

100-150

Product Questions & Answers (3)

Question by: Keith F on Dec 14, 2025, 5:40 PM
what's the temp range on this hose? got an application running coolant and want to make sure it holds up through winter and summer both
Answer by: Customer Support on Dec 16, 2025, 9:40 AM
Coolant service falls well within what this hose handles. The rated range runs from -55°F up to 300°F, so cold starts in deep winter and high-heat summer operation are both covered without issue. Just keep in mind that air brake service has a slightly tighter upper limit at 250°F rather than the full 300°F.
Question by: Ray M on Dec 14, 2025, 9:23 AM
Can this hose handle regular unleaded gas without falling apart on me?
Answer by: Customer Support on Dec 15, 2025, 5:03 PM
Absolutely. This AQP engine and air brake hose is designed for use with gasoline, fuel, lubricating oils, coolants, and air.
Question by: Pete C on Jan 4, 2026, 11:50 AM
got a tight spot on my truck, how sharp can i bend this hose without kinkin it
Answer by: Customer Support on Jan 6, 2026, 6:29 AM
For routing in cramped areas, the minimum bend radius is 2.75 inches. Keeping your bend at or above that radius helps it hold shape and avoid damage.
