AQP Single Wire Braid Blue SAE 100R5 Hose, 0.31 Inch ID, Up To 2250.00 PSI

Ask A Question

Description & Features

The AQP Single Wire Braid Blue SAE 100R5 Hose, 0.31 Inch ID, Up To 2250.00 PSI is engineered for robust performance in handling petroleum-based fluids, air, gasoline, fuel, and lubricating oil. This product features a durable AQP elastomer tube with a single wire braid reinforcement and a blue polyester braid cover ensuring premium abrasion resistance and extended life.

Specifically designed for hydraulics, this hose offers a maximum operating pressure of 2250 PSI and temperature range of -55deg;F to +300deg;F. The construction includes a polyester inner braid and an Ink Wheel lay line style, providing reliability and efficiency in demanding industrial applications.

With a minimum bend radius of 4 inches and a conductive design, this hose guarantees optimal fluid handling. It also boasts a significant impulse cycle life of 150000 cycles, which ensures consistent performance in challenging environments.

The hose's vacuum service rating is 28 inches of Hg, enhancing its versatility in various fluid transfer applications. The reel quantity ranges from 300-390 feet, making it suitable for diverse operational requirements.

Supplier Part Number: FC300-06RL

Specifications

Brand
Aeroquip® by Danfoss
Abrasion Resistance
Premium
Color
Blue
Conditional Temp Range
Air Not to Exceed 250 deg F
Construction
3-Ply Braided
Cover Material
Polyester
Dash Size
06
For Use With
Reusable Hose Fittings
grp Construction
AQP® Elastomer Tube, Polyester Inner Braid, 1-Wire Braided Reinforcement, Blue Polyester Braided Cover
Hose Color
Blue
Hose Type
Conductive
Impulse Cycle
100000
Impulse Cycle Life
150000
Inside Diameter
0.31 in
Lay Line Style
Ink Wheel
Nominal Size
#06
Package Form
Reel
Qualified Hose Fittings
Reusable
Reinforcement
3-Ply Braided Fabric
Reinforcement Material
Fabric
Resistance
Abrasion
Resistance Properties
Abrasion
Segment Code
A
Series
FC300 Series
Tube Material
Chlorinated Polyethylene

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
AQP Single Wire Braid Blue SAE 100R5 Hose, 0.88 Inch ID, Up To 800.00 PSI

FC300-16 AQP Single Wire SAE 100R5 Hose

0.88

1.27

800

7.38

20

170-210

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.19 Inch ID, Up To 3000.00 PSI

FC300-04 AQP Single Wire SAE 100R5 Hose

0.19

0.52

3000

3

28

490-640

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.25 Inch ID, Up To 3000.00 PSI

FC300-05 AQP Single Wire SAE 100R5 Hose

0.25

0.58

3000

3.38

28

390-510

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.41 Inch ID, Up To 2000.00 PSI

FC300-08 AQP Single Wire SAE 100R5 Hose

0.41

0.76

2000

4.62

28

450-600

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.50 Inch ID, Up To 1750.00 PSI

FC300-10 AQP Single Wire SAE 100R5 Hose

0.5

0.93

1750

5.5

28

300-390

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.62 Inch ID, Up To 1500.00 PSI

FC300-12 AQP Single Wire SAE 100R5 Hose

0.62

1.08

1500

6.5

28

230-300

AQP Single Wire Braid Blue SAE 100R5 Hose, 1.12 Inch ID, Up To 625.00 PSI

FC300-20 AQP Single Wire SAE 100R5 Hose

1.12

1.5

625

9

20

Rolls Only

AQP Single Wire Braid Blue SAE 100R5 Hose, 1.38 Inch ID, Up To 500.00 PSI

FC300-24 AQP Single Wire SAE 100R5 Hose

1.38

1.75

500

10.5

15

Rolls Only

AQP Single Wire Braid Blue SAE 100R5 Hose, 1.81 Inch ID, Up To 300.00 PSI

FC300-32 AQP Single Wire SAE 100R5 Hose

1.81

2.22

300

13.25

11

Rolls Only

AQP Single Wire Braid Blue SAE 100R5 Hose, 2.38 Inch ID, Up To 300.00 PSI

FC300-40 AQP Single Wire SAE 100R5 Hose

2.38

2.88

300

24

8

Rolls Only

Product Questions & Answers (3)

Question by: Ricky A on Aug 15, 2025, 11:23 AM
got a -6 line on a piece of equipment, is this the right size hose or am i mixin stuff up?
Answer by: Customer Support on Aug 17, 2025, 6:09 AM
For dash size, you are on the right track. This hose is a -6 with a 0.31 inch inside diameter and about a 0.67 inch outside diameter, so it matches what most folks mean when they say “-6 hose.”
Question by: Rhonda F on Aug 11, 2025, 6:03 AM
hose rated for fuel lines or just straight hydraulic fluid? got a mixed system running both and need something that'll hold up to both
Answer by: Customer Support on Aug 12, 2025, 11:35 AM
Petroleum-based fluids, gasoline, and fuel are all listed as approved media for this hose, so a mixed system running both hydraulic fluid and fuel falls within its intended use. The AQP elastomer tube handles that range well, and the 2250 PSI max operating pressure gives you solid headroom for hydraulic side demands. Just make sure your fittings and connections are rated for the same media range.
Question by: Wayne S on Apr 17, 2025, 7:52 AM
Will this hose hold up to regular use with hydraulic oil?
Answer by: Customer Support on Apr 18, 2025, 8:43 AM
It's definitely built for that. This hose is specifically designed for hydraulics and handles petroleum-based fluids like hydraulic oil, fuel, and lubricating oil without any problems.
