AQP Single Wire Braid Blue SAE 100R5 Hose, 0.41 Inch ID, Up To 2000.00 PSI

Ask A Question

Description & Features

The AQP Single Wire Braid Blue SAE 100R5 Hose, 0.41 Inch ID, Up To 2000.00 PSI by Danfoss Power Solutions (II LLC Aeroquip) is designed for hydraulic applications, handling petroleum-based fluids, air, gasoline, fuel, and lubricating oils. Featuring a premium abrasion-resistant blue polyester cover, it ensures durability in demanding environments.

With a conductive core and an AQP elastomer tube, this hose maintains efficient fluid conductivity and integrity. Its construction includes a polyester inner braid, single wire braid reinforcement, and a blue polyester braid cover, ensuring robust performance and long-lasting reliability.

The hose operates within a temperature range of -55deg;F to +300deg;F and has a maximum operating pressure of 2000 PSI. Its impulse cycle life of 150,000 cycles guarantees extended service life, while the minimum bend radius of 4.62 inches provides exceptional flexibility.

Ideal for diverse industrial fluid applications, this hose meets rigorous standards for handling fire-resistant hydraulic fluids and other industrial liquids. The lay line style is Ink Wheel, and it features a vacuum service capability of 28.

Supplier Part Number: FC300-08RL

Specifications

Brand
Aeroquip® by Danfoss
Abrasion Resistance
Premium
Color
Blue
Conditional Temp Range
Air Not to Exceed 250 deg F
Construction
3-Ply Braided
Cover Material
Polyester
Dash Size
08
For Use With
Reusable Hose Fittings
grp Construction
AQP® Elastomer Tube, Polyester Inner Braid, 1-Wire Braided Reinforcement, Blue Polyester Braided Cover
Hose Color
Blue
Hose Type
Conductive
Impulse Cycle
100000
Impulse Cycle Life
150000
Inside Diameter
0.41 in
Lay Line Style
Ink Wheel
Nominal Size
#08
Package Form
Reel
Qualified Hose Fittings
Reusable
Reinforcement
3-Ply Braided Fabric
Reinforcement Material
Fabric
Resistance
Abrasion
Resistance Properties
Abrasion
Segment Code
A
Series
FC300 Series
Tube Material
Chlorinated Polyethylene

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
AQP Single Wire Braid Blue SAE 100R5 Hose, 0.88 Inch ID, Up To 800.00 PSI

FC300-16 AQP Single Wire SAE 100R5 Hose

0.88

1.27

800

7.38

20

170-210

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.19 Inch ID, Up To 3000.00 PSI

FC300-04 AQP Single Wire SAE 100R5 Hose

0.19

0.52

3000

3

28

490-640

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.25 Inch ID, Up To 3000.00 PSI

FC300-05 AQP Single Wire SAE 100R5 Hose

0.25

0.58

3000

3.38

28

390-510

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.31 Inch ID, Up To 2250.00 PSI

FC300-06 AQP Single Wire SAE 100R5 Hose

0.31

0.67

2250

4

28

300-390

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.50 Inch ID, Up To 1750.00 PSI

FC300-10 AQP Single Wire SAE 100R5 Hose

0.5

0.93

1750

5.5

28

300-390

AQP Single Wire Braid Blue SAE 100R5 Hose, 0.62 Inch ID, Up To 1500.00 PSI

FC300-12 AQP Single Wire SAE 100R5 Hose

0.62

1.08

1500

6.5

28

230-300

AQP Single Wire Braid Blue SAE 100R5 Hose, 1.12 Inch ID, Up To 625.00 PSI

FC300-20 AQP Single Wire SAE 100R5 Hose

1.12

1.5

625

9

20

Rolls Only

AQP Single Wire Braid Blue SAE 100R5 Hose, 1.38 Inch ID, Up To 500.00 PSI

FC300-24 AQP Single Wire SAE 100R5 Hose

1.38

1.75

500

10.5

15

Rolls Only

AQP Single Wire Braid Blue SAE 100R5 Hose, 1.81 Inch ID, Up To 300.00 PSI

FC300-32 AQP Single Wire SAE 100R5 Hose

1.81

2.22

300

13.25

11

Rolls Only

AQP Single Wire Braid Blue SAE 100R5 Hose, 2.38 Inch ID, Up To 300.00 PSI

FC300-40 AQP Single Wire SAE 100R5 Hose

2.38

2.88

300

24

8

Rolls Only

Product Questions & Answers (4)

Question by: Janice C on Feb 28, 2026, 6:05 AM
got a tight spot to snake this hose through. what’s the smallest bend it’ll handle without kinking up?
Answer by: Customer Support on Mar 1, 2026, 11:06 AM
For routing, the minimum bend radius on this hose is 4.62 inches. Keeping your bend at or above that radius helps it flex as intended.
Question by: Warren S on Aug 4, 2025, 6:43 AM
What kind of fluids can this hose handle without breaking down?
Answer by: Customer Support on Aug 6, 2025, 6:30 AM
This hose is designed to handle petroleum-based fluids, air, gasoline, fuel, lubricating oil, and other industrial fluids. It's a good all-around option for hydraulics.
Question by: Pete W on Jan 19, 2026, 2:38 PM
rated for 2000 psi but what's the temp range on this thing, running petroleum fluid through it in a pretty hot environment
Answer by: Customer Support on Jan 21, 2026, 12:00 PM
Petroleum-based fluid applications can run up to 300 degrees F with this hose. The lower end holds down to negative 55 degrees F, so cold starts aren't a concern either. The one exception worth noting is air service, which is capped at 250 degrees F rather than 300. As long as your operating temps fall inside that window for your specific fluid type, you're in good shape.
Question by: Tommy P on Feb 8, 2026, 8:58 PM
got a tight spot to route it. how tight can i bend this hose without kinkin it
Answer by: Customer Support on Feb 10, 2026, 6:17 AM
For routing, the minimum bend radius is 4.62 inches. Keeping the bend at or above that radius helps prevent kinking and protects the reinforcement.
