AQP Single Wire Braid Blue SAE 100R5 Hose, 2.38 Inch ID, Up To 300.00 PSI

Description & Features

Engineered for premium abrasion resistance, the Eaton Aeroquip AQP Single Wire Braid Blue SAE 100R5 Hose features a robust construction ideal for hydraulic systems. With a 2.38-inch ID and a pressure rating of up to 300 PSI, this hose is designed to handle petroleum-based fluids, air, gasoline, fuel, lubricating oil, and other industrial fluids efficiently. Its blue polyester cover and conductive properties ensure both durability and safety in demanding environments.

The 3-braid construction enhances the hose's strength, making it suitable for a wide range of industrial applications. As part of the trusted Eaton Aeroquip brand, this hose meets the SAE 100R5 standard, ensuring reliable performance and compatibility with various hydraulic systems.

SKU: FC300-40

Supplier Part Number (MPN): FC300-40

Alternate Part Numbers: C1ZY17

Specifications

Brand Aeroquip® by Danfoss	Abrasion Resistance Premium	Color Blue	Conditional Temp Range Air Not to Exceed 250 deg F	Construction 3-Ply Braided	Cover Material Polyester	Dash Size 40	For Use With Reusable Hose Fittings	grp Construction AQP® Elastomer Tube, Polyester Inner Braid, 1-Wire Braided Reinforcement, Blue Polyester Braided Cover	Hose Color Blue	Hose Type Conductive	Impulse Cycle 100000	Impulse Cycle Life 150000	Lay Line Style Ink Wheel	Nominal Size #40	Package Form Bulk	Qualified Hose Fittings Reusable	Reinforcement 3-Ply Braided Fabric	Reinforcement Material Fabric	Resistance Abrasion	Resistance Properties Abrasion	Segment Code A	Series FC300 Series	Tube Material Chlorinated Polyethylene

Similar Products

Model Number	Hose I.D.	Hose O.D.	Maximum Operating Pressure	Minimum Bend Radius	Vacuum Service	Reel Qty (ft)
FC300-16 AQP Single Wire SAE 100R5 Hose	0.88	1.27	800	7.38	20	170-210
FC300-04 AQP Single Wire SAE 100R5 Hose	0.19	0.52	3000	3	28	490-640
FC300-05 AQP Single Wire SAE 100R5 Hose	0.25	0.58	3000	3.38	28	390-510
FC300-06 AQP Single Wire SAE 100R5 Hose	0.31	0.67	2250	4	28	300-390
FC300-08 AQP Single Wire SAE 100R5 Hose	0.41	0.76	2000	4.62	28	450-600
FC300-10 AQP Single Wire SAE 100R5 Hose	0.5	0.93	1750	5.5	28	300-390
FC300-12 AQP Single Wire SAE 100R5 Hose	0.62	1.08	1500	6.5	28	230-300
FC300-20 AQP Single Wire SAE 100R5 Hose	1.12	1.5	625	9	20	Rolls Only
FC300-24 AQP Single Wire SAE 100R5 Hose	1.38	1.75	500	10.5	15	Rolls Only
FC300-32 AQP Single Wire SAE 100R5 Hose	1.81	2.22	300	13.25	11	Rolls Only

Product Questions & Answers (3)

Question by: Clint J on Sep 8, 2025, 11:07 AM

What kind of fluids can this hose handle, besides just oil?

Answer by: Customer Support on Sep 10, 2025, 8:40 AM

It's rated to handle petroleum-based fluids, air, gasoline, fuel, lubricating oil, and some fire-resistant hydraulic fluids. Just make sure to double-check that your specific fluid is compatible.

Question by: Steve S on Feb 27, 2026, 4:28 PM

got a fuel line setup that needs a big 2.38 inch ID hose. is this one meant for fuel and oil or is it more of a hydraulic-only deal

Answer by: Customer Support on Feb 28, 2026, 6:30 PM

For fluid type, it’s intended for hydraulics handling petroleum based fluids, plus air, gasoline, fuel, lubricating oil, and other industrial fluids.

Question by: Cheryl R on Apr 21, 2025, 8:32 PM

hose is 2.38 inch ID, that's a pretty big bore. what kind of applications is this thing typically used for?

Answer by: Customer Support on Apr 23, 2025, 8:34 AM

At that inside diameter, you're looking at high-volume fluid transfer work. The FC300 series is built for petroleum-based fluids, fuel, gasoline, lubricating oil, and air lines in industrial and engine-related setups. The large bore handles applications where you need serious flow capacity without choking down the line.
