AQP Wire Inserted Suction SAE 100R4 Blue Hose, 0.75 Inch ID, Up To 300.00 PSI

Ask A Question

Description & Features

This Eaton Aeroquip wire-inserted suction hose is designed for suction applications involving hydraulic and lubrication oils, gasoline, air, water, and chemical transfer.

The AQP Wire Inserted Suction SAE 100R4 Blue Hose features a conductive elastomer cover material for abrasion resistance and a 2-ply braid construction. It has a 0.75 inch inside diameter and is rated for up to 300 PSI.

SKU: 2661-12

Supplier Part Number (MPN): 2661-12

Alternate Part Numbers: C1BJ20

Specifications

Abrasion Resistance
29
Application
Suction application for hydraulic, lubrication oils, gasoline, air, water and chemical transfer.
Color
Blue
Conductivity
30
Construction
2-ply braid
Cover Material
Elastomer
Dash Size
-12
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Hose I.D.
0.75
Hose O.D.
1.25
Impulse Cycle Life
500000 cycle
Lay Line Style
Embossed
Maximum Operating Pressure
300
Minimum Bend Radius
5
Minimum Working Temperature
-40
Reel Qty (ft)
Rolls Only
Reinforcement Material
Helical Wire and Textile
Supplier Part Number
2661-12
Tube Material
Synthetic Rubber
Vacuum Service
28
Alternate Part Numbers
Alternate Part Number C1BJ20, Alternate Part Number MINO-00015F72456
Product Weight
1.34 lbs

Related Documents

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.25 Inch ID, Up To 200.00 PSI

2661-20 AQP Wire Inserted Suction Hose

1.25

1.8

200

8

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.00 Inch ID, Up To 250.00 PSI

2661-16 AQP Wire Inserted Suction Hose

1

1.5

250

6

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.50 Inch ID, Up To 150.00 PSI

2661-24 AQP Wire Inserted Suction Hose

1.5

2.06

150

10

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 2.00 Inch ID, Up To 100.00 PSI

2661-32 AQP Wire Inserted Suction Hose

2

2.55

100

12

28

Rolls Only

Product Questions & Answers (2)

Question by: Darryl J on Dec 6, 2025, 3:13 PM
got a suction line that needs 3/4 inch hose, is this one actually 0.75" ID and what dash size is it
Answer by: Customer Support on Dec 7, 2025, 4:54 PM
For sizing, it’s a 0.75 inch inside diameter hose and it’s listed as dash size -12.
Question by: Ronnie M on Oct 12, 2025, 5:07 PM
what all can this hose handle fluid-wise? trying to figure out if it'll work for more than just hydraulic oil on our equipment
Answer by: Customer Support on Oct 14, 2025, 6:09 AM
Suction lines pulling hydraulic fluid are the obvious fit, but this hose is also rated for lubrication oils, gasoline, air, water, and chemical transfer. So if you're running multiple fluid types through different parts of the same setup, there's a good chance this one covers more of your needs than you'd expect from a single hose spec.
