main product photo

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.25 Inch ID, Up To 200.00 PSI

Ask A Question

Description & Features

Description & Features

Designed for various industrial applications, the AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.25 Inch ID, Up To 200.00 PSI, offers reliable performance for suction and transfer of hydraulic fluids, lubricating oils, gasoline, air, water, and chemicals. This hose is constructed with a rugged AQPreg; elastomer tube reinforced with a helical wire and two textile braids, topped with a durable blue AQPreg; elastomer cover.

Featuring a 2-ply braid construction, it maintains flexibility and strength. It operates efficiently up to a pressure of 200 PSI and withstands temperatures ranging from -40deg;F to +300deg;F. Its minimum bend radius of 8 inches ensures adaptability in tight spaces while ensuring consistent performance.

The abrasion-resistant cover and conductive properties enhance safety and longevity, making it suitable for demanding environments. Compatible with Global TTC fittings and shank type combination nipples, installation is straightforward using T-Bolt or preformed clamps.

MPN: C1BJ22

Supplier Part Number: 2661-20

Specifications

Abrasion Resistance
29
Application
Suction application for hydraulic, lubrication oils, gasoline, air, water and chemical transfer.
Color
Blue
Conductivity
30
Construction
2-ply braid
Cover Material
Elastomer
Dash Size
-20
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Hose I.D.
1.25
Hose O.D.
1.80
Impulse Cycle Life
500000 cycle
Lay Line Style
Embossed
Maximum Operating Pressure
200
Minimum Bend Radius
8
Minimum Bend Radius
8
Minimum Working Temperature
-40
Reel Qty (ft)
Rolls Only
Reinforcement Material
Helical Wire and Textile
Supplier Part Number
2661-20
Tube Material
Synthetic Rubber
Vacuum Service
28
Alternate Part Numbers
Alternate Part Number C1BJ22, Alternate Part Number MINO-00015F43683
Product Weight
2.06 lbs

Related Documents

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.00 Inch ID, Up To 250.00 PSI

2661-16 AQP Wire Inserted Suction Hose

1

1.5

250

6

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.50 Inch ID, Up To 150.00 PSI

2661-24 AQP Wire Inserted Suction Hose

1.5

2.06

150

10

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 2.00 Inch ID, Up To 100.00 PSI

2661-32 AQP Wire Inserted Suction Hose

2

2.55

100

12

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 0.75 Inch ID, Up To 300.00 PSI

2661-12 AQP Wire Inserted Suction Hose

0.75

1.25

300

5

28

Rolls Only

Product Questions & Answers (4)

Question by: Wes W on Nov 2, 2025, 5:17 PM
trying to run hot phosphate ester fluid through my setup. what kind of heat can the hose handle before the rubber starts breaking down
Answer by: Customer Support on Nov 4, 2025, 6:16 AM
Operating temperatures for the AQP elastomer material safely range from negative 40 up to 300 degrees Fahrenheit. The synthetic rubber tube and blue cover are fully rated to transfer petroleum and phosphate ester hydraulic fluids without degrading under those extreme conditions.
Question by: Dwayne H on Jul 14, 2025, 3:08 PM
got a suction line that needs 1-1/4 inch ID, is this the one and what size is it on the outside
Answer by: Customer Support on Jul 16, 2025, 6:18 AM
For fit and routing, the inside diameter is 1.25 inch and the outside diameter is 1.8 inch. The minimum bend radius is 8 inches, so it needs a fairly gentle sweep when you lay it in.
Question by: Lyle D on Oct 15, 2025, 6:19 AM
got a tight spot to snake this through. how sharp can i bend that 1-1/4 suction hose without kinkin it up
Answer by: Customer Support on Oct 17, 2025, 6:47 AM
For routing, the minimum bend radius is 8 inches. Keeping your bend at or above that helps it stay flexible without collapsing or kinking, which matters on suction lines.
Question by: Eddie W on Jan 13, 2026, 5:38 PM
What kind of fittings work with this hose? Just wanna make sure I get the right ones.
Answer by: Customer Support on Jan 15, 2026, 6:55 AM
Global TTC fittings and shank type combination nipples are compatible, so you're good to go with those. Use T-Bolt or preformed clamps for installation.
