AQP Wire Inserted Suction SAE 100R4 Blue Hose, 2.00 Inch ID, Up To 100.00 PSI

Ask A Question

Description & Features

This Eaton Aeroquip AQP hose is designed for suction applications involving hydraulic and lubrication oils, gasoline, air, water, and chemical transfer.

Featuring a blue elastomer cover, this AQP Wire Inserted Suction SAE 100R4 Blue Hose has a 2.00 inch ID and can handle pressures up to 100.00 PSI. Its construction incorporates a 2-ply braid for enhanced durability and standard abrasion resistance, and it is also conductive.

SKU: 2661-32

Supplier Part Number (MPN): 2661-32

Alternate Part Numbers: C1BJ24

Specifications

Abrasion Resistance
29
Application
Suction application for hydraulic, lubrication oils, gasoline, air, water and chemical transfer.
Color
Blue
Conductivity
30
Construction
2-ply braid
Cover Material
Elastomer
Dash Size
-32
Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
12.00
UOM
FT
Hose I.D.
2
Hose O.D.
2.55
Impulse Cycle Life
500000 cycle
Lay Line Style
Embossed
Maximum Operating Pressure
100
Minimum Bend Radius
12
Minimum Bend Radius
12
Minimum Working Temperature
-40
Reel Qty (ft)
Rolls Only
Reinforcement Material
Helical Wire and Textile
Supplier Part Number
2661-32
Tube Material
Synthetic Rubber
Vacuum Service
28
Alternate Part Numbers
Alternate Part Number C1BJ24, Alternate Part Number MINO-00015F72461
Product Weight
4.48 lbs

Related Documents

Similar Products

Model Number Hose I.D. Hose O.D. Maximum Operating Pressure Burst Pressure Minimum Bend Radius Vacuum Service Reel Qty (ft) Price Action
AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.25 Inch ID, Up To 200.00 PSI

2661-20 AQP Wire Inserted Suction Hose

1.25

1.8

200

8

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.00 Inch ID, Up To 250.00 PSI

2661-16 AQP Wire Inserted Suction Hose

1

1.5

250

6

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 1.50 Inch ID, Up To 150.00 PSI

2661-24 AQP Wire Inserted Suction Hose

1.5

2.06

150

10

28

Rolls Only

AQP Wire Inserted Suction SAE 100R4 Blue Hose, 0.75 Inch ID, Up To 300.00 PSI

2661-12 AQP Wire Inserted Suction Hose

0.75

1.25

300

5

28

Rolls Only

Product Questions & Answers (2)

Question by: Warren W on Jul 12, 2025, 1:54 PM
got a 2 inch suction line on a hydraulic reservoir, is this hose the right kind for that or is it more for pressure?
Answer by: Customer Support on Jul 14, 2025, 6:20 AM
For a suction setup, it fits the job. It is an SAE 100R4 wire inserted suction hose with a 2.00 inch inside diameter, and it is rated up to 100 PSI max operating pressure. The reinforcement includes a helical wire between two textile braids, which is what helps it hold shape on suction.
Question by: Stan B on Apr 21, 2025, 9:21 AM
What kind of stuff can I use this hose for? I need it for suction.
Answer by: Customer Support on Apr 23, 2025, 7:33 AM
This Aeroquip hose is designed for suction applications involving hydraulic and lubrication oils, gasoline, air, water, and some chemical transfers.
