Base Channel For Pipe & Tubing Support Clamps, 48 Inch Long, 0.81 Inch Height, 316 SS

Description & Features

Available in various lengths and materials, the Base Channel For Pipe & Tubing Support Clamps is engineered for adaptability and efficiency. Each channel is crafted from 316 stainless steel, known for its durability and resistance to corrosion. The 48-inch length and 0.81-inch height specifications make it an optimal choice for multiple industrial settings.

The 316 SS material ensures longevity and robust performance in harsh environments. Its straightforward installation process allows for quick mounting, ensuring minimal disruption during assembly or maintenance.

The cushion's temperature range of -65deg;F to 275deg;F provides excellent thermal stability, accommodating a wide range of operational conditions. The channels support easy removal or addition of fluid conductors without impacting adjacent ones, maintaining system integrity.

Brand: HYDRA-ZORB CO

Supplier Part Number: 121048-6-101

Specifications

Brand ZSI	Brand ZSI	Pack Size 1.00	UOM EA	Height 0.81	Length 48	Materials 316 SS	Supplier Part Number 121048-6-101	Thread Sealant No	Alternate Part Numbers Alternate Part Number C1EX40	Product Weight 3.75 lbs

Similar Products

Model Number	Type	Materials	Length	Height	Price	Action
121048-1-203 Base Channel For Support Clamp	Single	12 gauge mild steel	48	1
121048-6-101 Base Channel For Support Clamp	Single	316 SS	48	0.8125

Product Questions & Answers (2)

Question by: Chad H on Oct 2, 2025, 4:32 PM

got a clamp setup already, what exactly is this channel piece doing for me

Answer by: Customer Support on Oct 3, 2025, 6:54 PM

As the base channel in a pipe and tubing support clamp system, it gives you a mounting track for the clamps so lines can be supported in a clean, organized run. One handy part is you can remove or add a fluid conductor without having to disturb the ones next to it.

Question by: Janet F on Sep 25, 2025, 8:14 AM

What kind of environments can this channel handle, like temperature-wise?

Answer by: Customer Support on Sep 27, 2025, 7:26 AM

The cushion in this channel is rated to handle temperatures from -65°F up to 275°F.
