304SS 2.5" 0 - 30Hg/ 0- -1.0 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

This high-quality gauge from Engineered Specialty Products features a 2.5" dial and a 1/4 NPT bottom connection. The robust 304 stainless steel construction ensures a long service life and durability in demanding industrial environments.

With measurement ranges from 0 to 30Hg and 0 to -1.0 Bar it provides precise readings. The liquid-filled design dampens vibrations and pulsations enhancing measurement reliability.

The brass male connection includes a 0.013" throttle plug for added durability. Clear visibility is ensured by the polycarbonate window protecting the internal components from damage.

The compact dimensions with A=2.48 B=1.21 C=2.71 and D=0.46 allow installation in limited spaces without sacrificing performance. Accurate to 3-2-3% of the span this gauge is a reliable choice for various applications.

MPN: 648952

Supplier Part Number: PRO-201L-254A

Specifications

Calibrated No	Case Included No	Dimensions A=2.48 B=1.21 C=2.71 D=0.46	Brand Engineered Specialty Products – Esp	Brand Engineered Specialty Products	Pack Size 1.00	UOM EA	Fill Type Liquid Filled	Materials 304SS	Specifications 2.5" 0 - 30Hg/ 0- -1.0 Bar	Supplier Part Number PRO-201L-254A	Thread 1 1/4 NPT	Alternate Part Numbers Alternate Part Number 574018, Alternate Part Number 638008A4G02LP0LBR30IMV24202, Alternate Part Number 648952, Alternate Part Number 888064648952, Alternate Part Number C1ND83, Alternate Part Number MI-08734215, Alternate Part Number MINO-01117X96000	Product Weight 0.99 lbs

Similar Products

Model Number	Part Number	Specifications	Fill Type	Thread 1	Materials	Dimensions
PRO-201L-254U Bottom Connect Pressure Gauge	PRO-201L-254U	2.5" 0-10,000 PSI/ 0-700 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
465866 Bottom Connect Pressure Gauge	465866	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge	PRO-201L-254B	2.5" 0-15 PSI / 0-1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge	PRO-201L-254F	2.5" 0-160 PSI/ 0-11 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H Bottom Connect Pressure Gauge	PRO-201L-254H	2.5" 0-300 PSI/ 0-20 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC Bottom Connect Pressure Gauge	PRO-201L-254CC	2.5" 30Hg-30 PSI/ -1.0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M Bottom Connect Pressure Gauge	PRO-201L-254M	2.5" 0-1,000 PSI/ 0-70 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649027 Bottom Connect Pressure Gauge	649027	2.5" 0-100 PSI/ 0-7 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge	PRO-201L-254O	2.5" 0-2,000 PSI/ 0-140 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge	PRO-201L-254CB	2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q Bottom Connect Pressure Gauge	PRO-201L-254Q	2.5" 0-4,000 PSI/ 0-280 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649140 Bottom Connect Pressure Gauge	649140	2.5" 0-5,000 PSI/ 0-350 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge	PRO-201L-254V	2.5" 0-15,000 PSI/ 0-1000 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649065 Bottom Connect Pressure Gauge	649065	2.5" 0-200 PSI/ 0-14 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge	648990	2.5" 0-30 PSI/ 0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge	649010	2.5" 0-60 PSI/ 0-4.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P Bottom Connect Pressure Gauge	PRO-201L-254P	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge	PRO-201L-254K	2.5" 0-600 PSI/ 0-40 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge	PRO-201L-254N	2.5" 0-1,500 PSI/ 0-100 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46

Product Questions & Answers (2)

Question by: Melvin F on Jul 18, 2025, 9:36 PM

got a 1/4 npt port on the bottom, is that what this gauge threads into or am i missing something?

Answer by: Customer Support on Jul 20, 2025, 6:40 AM

For fitment, it uses a 1/4 NPT male bottom connection, so it threads into a matching 1/4 NPT female port.

Question by: Scott R on Mar 26, 2026, 1:33 PM

gauge says it goes to 30Hg vacuum -- is that the full range or just one side of a dual scale?

Answer by: Customer Support on Mar 28, 2026, 8:13 AM

Full vacuum range on this one. It reads from 0 to 30 inches of mercury on the Hg scale, which also corresponds to 0 to negative 1.0 bar. Both scales are on the same dial showing the same range, just in different units. There's no positive pressure side to this gauge -- it's strictly a vacuum measurement instrument.
