304SS 2.5" 0-15 PSI / 0-1.0 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

Crafted from 304 stainless steel this gauge delivers durability and reliable performance in industrial applications. The 2.5" dial along with a measurement range of 0-15 PSI / 0-1.0 Bar ensures accurate and clear pressure readings.

The liquid-filled design reduces the effects of vibration and pulsation providing stable measurements. The 1/4 NPT brass bottom connection offers secure and efficient attachment suitable for various demanding environments.

The polycarbonate window is impact-resistant combining safety and longevity. Rated with an accuracy of 3% over the first and last quarters of the scale and 2% over the middle half this instrument ensures precise readings.

Normal operating pressures are best maintained between 25% to 75% of the scale while the 0.013" throttle plug in the male connection aids in effective pressure regulation.

MPN: 63 1008AL 02L 15#-9815

Supplier Part Number: PRO-201L-254B

Specifications

Brand
PIC Gauges
a Dimensions
2.48 in
b Dimensions
1.21 in
c Dimensions
2.71 in
Calibrated
Without Calibrated
Case Included
Without Case
Color
Black/White
Connection Type
NPT
d Dimensions
0.46 in
Dial Face
Polycarbonate
Dimensions
2.65 in H x 1.21 in W
Fill Medium
Glycerin
Fill Type
Liquid Filled
Gauge Size
2-1/2 in Dia
Gauge Type
Industrial Vacuum
Material
Stainless Steel
Series
Pro 200 Series
Sg Accuracy
+/-3-2-3% of Span +/-3% over First and Last Quarters of the Scale, +/-2% over the Middle Half of the Scale
Sg Male Connection
0.013 in Brass Throttle Plug

Similar Products

Model Number Measuring Range Connection Type Price Action
304SS 2.5

649027 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254A Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge

NPT

304SS 2.5

649065 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254M Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254P Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254U Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254H Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge

NPT

304SS 2.5

465866 Bottom Connect Pressure Gauge

MNPT

304SS 2.5

649140 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254CC Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254Q Bottom Connect Pressure Gauge

NPT

649157

649157

NPT

SS/BRASS, CENTER BACK, 2 1/2 DIAL, 1/4

PRO-201L-254T

NPT

Product Questions & Answers (1)

Question by: Jean G on Aug 26, 2025, 2:36 PM
What size is the threaded connection on this gauge?
Answer by: Customer Support on Aug 28, 2025, 6:32 AM
It comes with a 1/4 NPT bottom connection made of brass.
