304SS 2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

Maximize precision with the 2.5" liquid filled pressure gauge engineered with high-grade 304 stainless steel. Ideal for demanding industrial environments it covers a range of 30Hg to 15 PSI or -1.0 to 1.0 Bar.

Designed by Engineered Specialty Products the robust construction incorporates a 1/4 NPT bottom connection for seamless integration. The polycarbonate window ensures clarity and durability complemented by a brass male connection featuring a 0.013" throttle plug.

Accuracy is ensured across the span with a tolerance of 3-2-3%. The gauge is liquid filled enhancing stability and reducing needle flutter making it suitable for applications with fluctuating pressures.

To maintain optimal performance it is recommended that the operating pressure be kept within 25%-75% of the gauge scale and not exceed 50% if pulsation is present.

Model Number: 63 1008AL 02L 15#/V-9816

Supplier Part Number: PRO-201L-254CB

Specifications

Calibrated No	Case Included No	Dimensions A=2.48 B=1.21 C=2.71 D=0.46	Brand Engineered Specialty Products – Esp	Brand Engineered Specialty Products	Pack Size 1.00	UOM EA	Fill Type Liquid Filled	Materials 304SS	Specifications 2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Supplier Part Number PRO-201L-254CB	Thread 1 1/4 NPT	Alternate Part Numbers Alternate Part Number 574032, Alternate Part Number 638008A4G02LP0LBRV15242-04, Alternate Part Number 638008A4G02LP0LBRV1524204, Alternate Part Number 648983, Alternate Part Number 888064648983, Alternate Part Number C1ND84, Alternate Part Number MI-08734217, Alternate Part Number MINO-01117X96002	Product Weight 0.99 lbs

Similar Products

Model Number	Part Number	Specifications	Fill Type	Thread 1	Materials	Dimensions
PRO-201L-254U Bottom Connect Pressure Gauge	PRO-201L-254U	2.5" 0-10,000 PSI/ 0-700 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
465866 Bottom Connect Pressure Gauge	465866	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge	PRO-201L-254B	2.5" 0-15 PSI / 0-1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge	PRO-201L-254F	2.5" 0-160 PSI/ 0-11 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H Bottom Connect Pressure Gauge	PRO-201L-254H	2.5" 0-300 PSI/ 0-20 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254A Bottom Connect Pressure Gauge	PRO-201L-254A	2.5" 0 - 30Hg/ 0- -1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC Bottom Connect Pressure Gauge	PRO-201L-254CC	2.5" 30Hg-30 PSI/ -1.0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M Bottom Connect Pressure Gauge	PRO-201L-254M	2.5" 0-1,000 PSI/ 0-70 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649027 Bottom Connect Pressure Gauge	649027	2.5" 0-100 PSI/ 0-7 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge	PRO-201L-254O	2.5" 0-2,000 PSI/ 0-140 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge	PRO-201L-254CB	2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q Bottom Connect Pressure Gauge	PRO-201L-254Q	2.5" 0-4,000 PSI/ 0-280 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649140 Bottom Connect Pressure Gauge	649140	2.5" 0-5,000 PSI/ 0-350 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge	PRO-201L-254V	2.5" 0-15,000 PSI/ 0-1000 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649065 Bottom Connect Pressure Gauge	649065	2.5" 0-200 PSI/ 0-14 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge	648990	2.5" 0-30 PSI/ 0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge	649010	2.5" 0-60 PSI/ 0-4.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P Bottom Connect Pressure Gauge	PRO-201L-254P	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge	PRO-201L-254K	2.5" 0-600 PSI/ 0-40 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge	PRO-201L-254N	2.5" 0-1,500 PSI/ 0-100 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46

Product Questions & Answers (3)

Question by: Ricky G on May 15, 2025, 4:58 PM

Can this handle a little vibration, or does it need to be mounted somewhere real stable?

Answer by: Customer Support on May 17, 2025, 3:08 PM

Liquid filling helps dampen vibration and pulsations, so it should give you more stable readings even if things aren't perfectly still. Keep the pressure within 25%-75% of the scale for the best performance, and under 50% if you've got a lot of vibration.

Question by: Steve H on Feb 7, 2026, 10:57 AM

gauge reads vacuum and positive pressure both, that what the 30Hg to 15 PSI range means, or am i reading that wrong?

Answer by: Customer Support on Feb 8, 2026, 7:47 PM

You're reading it right. That range covers both sides of atmospheric pressure. The negative side goes down to 30 inches of mercury, which is full vacuum, and the positive side tops out at 15 PSI. So if your process pulls a vacuum and then pressurizes, this one gauge handles the whole swing without needing two separate instruments.

Question by: Brett H on Apr 9, 2025, 2:03 PM

got a system that bounces around a bit, will this gauge quit flutterin all over the place?

Answer by: Customer Support on Apr 11, 2025, 6:16 AM

Liquid fill helps steady the needle when pressure is fluctuating, so it is a good fit for systems that tend to pulse or vibrate. For best results, keep normal operating pressure in the 25% to 75% part of the scale, and if pulsation is present do not run it over 50% of full scale.
