304SS 2.5" 0-30 PSI/ 0-2.0 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

Designed for accurate pressure measurement this liquid-filled gauge features a robust 304 stainless steel construction ensuring durability and resistance to corrosion. The 2.5-inch dial provides clear and precise readings within a range of 0-30 PSI (0-2.0 Bar). Suitable for diverse industrial applications it includes a 1/4 NPT brass bottom connection and a polycarbonate window for enhanced protection.

The gauge operates with a 3-2-3% of span accuracy offering reliable performance through varying conditions. Its recommended to confine normal operating pressure to 25%-75% of the scale for optimal results. When pulsation is present maximum operating pressure should not exceed 50% of the full-scale range.

With model number 63 1008AL 02L 30#-9817 and catalog number C1ND87 this product is an essential component for monitoring and maintaining accurate pressure levels in your specialized field. The liquid fill type improves gauge stability and prolongs its lifespan by reducing the effects of vibration and pulsation.

MPN: 63 1008AL 02L 30#-9817

Supplier Part Number: PRO-201L-254C

Specifications

Calibrated No	Case Included No	Dimensions A=2.48 B=1.21 C=2.71 D=0.46	Brand Engineered Specialty Products	Brand Engineered Specialty Products	Pack Size 1.00	UOM EA	Fill Type Liquid Filled	Materials 304SS	Specifications 2.5" 0-30 PSI/ 0-2.0 Bar	Supplier Part Number PRO-201L-254C	Thread 1 1/4 NPT	Alternate Part Numbers Alternate Part Number 574049, Alternate Part Number 631008AL02L30#-9817, Alternate Part Number 638008A4G02LP0LBR3024205, Alternate Part Number 91015388, Alternate Part Number C1ND87, Alternate Part Number MI-08734254, Alternate Part Number MINO-01117X96003	Product Weight 0.00 lbs

Similar Products

Model Number	Part Number	Specifications	Fill Type	Thread 1	Materials	Dimensions
PRO-201L-254U Bottom Connect Pressure Gauge	PRO-201L-254U	2.5" 0-10,000 PSI/ 0-700 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
465866 Bottom Connect Pressure Gauge	465866	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge	PRO-201L-254B	2.5" 0-15 PSI / 0-1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge	PRO-201L-254F	2.5" 0-160 PSI/ 0-11 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H Bottom Connect Pressure Gauge	PRO-201L-254H	2.5" 0-300 PSI/ 0-20 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254A Bottom Connect Pressure Gauge	PRO-201L-254A	2.5" 0 - 30Hg/ 0- -1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC Bottom Connect Pressure Gauge	PRO-201L-254CC	2.5" 30Hg-30 PSI/ -1.0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M Bottom Connect Pressure Gauge	PRO-201L-254M	2.5" 0-1,000 PSI/ 0-70 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649027 Bottom Connect Pressure Gauge	649027	2.5" 0-100 PSI/ 0-7 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge	PRO-201L-254O	2.5" 0-2,000 PSI/ 0-140 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge	PRO-201L-254CB	2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q Bottom Connect Pressure Gauge	PRO-201L-254Q	2.5" 0-4,000 PSI/ 0-280 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649140 Bottom Connect Pressure Gauge	649140	2.5" 0-5,000 PSI/ 0-350 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge	PRO-201L-254V	2.5" 0-15,000 PSI/ 0-1000 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649065 Bottom Connect Pressure Gauge	649065	2.5" 0-200 PSI/ 0-14 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge	648990	2.5" 0-30 PSI/ 0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge	649010	2.5" 0-60 PSI/ 0-4.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P Bottom Connect Pressure Gauge	PRO-201L-254P	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge	PRO-201L-254K	2.5" 0-600 PSI/ 0-40 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge	PRO-201L-254N	2.5" 0-1,500 PSI/ 0-100 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46

Product Questions & Answers (2)

Question by: Scott R on Feb 25, 2026, 6:47 PM

i’ve got a 1/4 npt port on the bottom of my manifold. is this gauge the bottom connection style or is it a back mount?

Answer by: Customer Support on Feb 27, 2026, 8:59 AM

Bottom connection on this one. It has a 1/4 NPT male brass fitting on the bottom, and the dial size is 2.5 inches.

Question by: Ralph A on Jun 9, 2025, 8:18 AM

gauge says liquid filled, what's that actually doing for me out in the field?

Answer by: Customer Support on Jun 11, 2025, 6:38 AM

Liquid fill dampens the internal movement of the gauge, which cuts down on needle flutter when there's vibration or pulsation in the line. That means you get a steadier, more readable needle and less wear on the internals over time. For equipment that runs rough or surges, it makes a real difference in how long the gauge holds up and how accurately it reads day to day.
