304SS 2.5" 0-60 PSI/ 0-4.0 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

Optimize the accuracy and reliability of your pressure monitoring needs with this precision-engineered liquid-filled gauge. Constructed from durable 304 stainless steel the 2.5" dial is designed for readings from 0-60 PSI and 0-4.0 Bar ensuring consistent performance even in demanding industrial environments. The 1/4 NPT bottom connection features a brass male connection with a 0.013" throttle plug. The polycarbonate window provides clear visibility and withstands challenging conditions while the liquid-filled design helps to minimize the effects of vibration and pulsation. The gauge offers an accuracy of 3-2-3% of the span providing reliable readings within specified tolerances. The pressure gauge is recommended to be used between 25%-75% of the scale for optimal performance with a maximum operational gauge pressure at 50% of the full-scale range in pulsating conditions. With dimensions of A=2.48 B=1.21 C=2.71 and D=0.46 this model is suitable for various industrial applications. MPN: 63 1008AL 02L 60#-9819 Supplier Part Number: PRO-201L-254D

Specifications

Calibrated No	Case Included No	Dimensions A=2.48 B=1.21 C=2.71 D=0.46	Brand Engineered Specialty Products	Brand Engineered Specialty Products	Pack Size 1.00	UOM EA	Fill Type Liquid Filled	Materials 304SS	Specifications 2.5" 0-60 PSI/ 0-4.0 Bar	Supplier Part Number PRO-201L-254D	Thread 1 1/4 NPT	Alternate Part Numbers Alternate Part Number 210244, Alternate Part Number 574063, Alternate Part Number 638008A4G02LP0LBR60242-07, Alternate Part Number 888064649010, Alternate Part Number 91015389, Alternate Part Number ASHCROFT 63 1008AL 02B 60#-9835, Alternate Part Number C1ND88, Alternate Part Number MI-08734279, Alternate Part Number MINO-01117X96005	Product Weight 0.00 lbs

Similar Products

Model Number	Part Number	Specifications	Fill Type	Thread 1	Materials	Dimensions
PRO-201L-254U Bottom Connect Pressure Gauge	PRO-201L-254U	2.5" 0-10,000 PSI/ 0-700 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
465866 Bottom Connect Pressure Gauge	465866	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge	PRO-201L-254B	2.5" 0-15 PSI / 0-1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge	PRO-201L-254F	2.5" 0-160 PSI/ 0-11 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H Bottom Connect Pressure Gauge	PRO-201L-254H	2.5" 0-300 PSI/ 0-20 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254A Bottom Connect Pressure Gauge	PRO-201L-254A	2.5" 0 - 30Hg/ 0- -1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC Bottom Connect Pressure Gauge	PRO-201L-254CC	2.5" 30Hg-30 PSI/ -1.0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M Bottom Connect Pressure Gauge	PRO-201L-254M	2.5" 0-1,000 PSI/ 0-70 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649027 Bottom Connect Pressure Gauge	649027	2.5" 0-100 PSI/ 0-7 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge	PRO-201L-254O	2.5" 0-2,000 PSI/ 0-140 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge	PRO-201L-254CB	2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q Bottom Connect Pressure Gauge	PRO-201L-254Q	2.5" 0-4,000 PSI/ 0-280 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649140 Bottom Connect Pressure Gauge	649140	2.5" 0-5,000 PSI/ 0-350 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge	PRO-201L-254V	2.5" 0-15,000 PSI/ 0-1000 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649065 Bottom Connect Pressure Gauge	649065	2.5" 0-200 PSI/ 0-14 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge	648990	2.5" 0-30 PSI/ 0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge	649010	2.5" 0-60 PSI/ 0-4.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P Bottom Connect Pressure Gauge	PRO-201L-254P	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge	PRO-201L-254K	2.5" 0-600 PSI/ 0-40 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge	PRO-201L-254N	2.5" 0-1,500 PSI/ 0-100 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46

Product Questions & Answers (2)

Question by: Cindy B on Apr 2, 2025, 8:34 AM

reckon this gauge can handle up to 60 psi without any issues on a standard hydraulic setup

Answer by: Customer Support on Apr 4, 2025, 6:14 AM

It'll measure pressures from 0 to 60 PSI or 0 to 4.0 Bar just fine, thanks to its liquid-filled design that helps with vibration and pulsation in hydraulic systems. The 1/4 NPT bottom connection makes it straightforward to hook up.

Question by: Darryl W on Jun 11, 2025, 1:10 PM

will this fit where i got a 1/4 npt bottom mount now that goes to 100 psi but only reads up to 60?

Answer by: Customer Support on Jun 12, 2025, 4:25 PM

Absolutely, the threading and bottom connection will match your current setup perfectly. Keep in mind though that this gauge maxes out at 60 PSI, so if your system runs between 60-100 PSI regularly, you'll be pegging the needle at the top of the scale which isn't great for accuracy or gauge life. You'd want to size your pressure gauge so normal operating pressure falls around the middle of the range for best results.
