304SS 2.5" 0-100 PSI/ 0-7 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

The 304SS 2.5" 0-100 PSI/ 0-7 Bar Liquid Filled Pressure Gauge 1/4 NPT Bottom Connection exemplifies precision in pressure measurement. Engineered Specialty Products delivers this robust pressure gauge constructed from durable 304 stainless steel ensuring long-lasting performance.

The gauge features a 2.5" diameter dial offering clear and accurate readings for a range of industrial applications. Its liquid-filled design mitigates the effects of vibration and pulsation enhancing reliability and stability.

This gauge's 1/4 NPT bottom connection is crafted from high-quality brass with a 0.013" throttle plug suitable for various technical setups. The gauge maintains accuracy within 3-2-3% across its span making it a reliable choice for monitoring pressure levels up to 100 PSI or 7 Bar.

For optimal performance the recommended pressure range for normal operations is 25%-75% of the scale reducing potential strain and ensuring accurate readings.

Specifications include A=2.48 B=1.21 C=2.71 and D=0.46 dimensions enhancing versatility and compatibility within different system designs. The gauge also boasts a polycarbonate window providing clear visibility and resistance to impact.

Supplier Part Number: PRO-201L-254E

Specifications

Brand
PIC Gauges
a Dimensions
2.48 in
b Dimensions
1.21 in
c Dimensions
2.71 in
Calibrated
Without Calibrated
Case Included
Without Case
Color
Black
Connection Type
NPT
d Dimensions
0.46 in
Dial Face
Polycarbonate
Dimensions
2.65 in H x 1.21 in W
Fill Medium
Glycerin
Fill Type
Liquid Filled
Gauge Size
2-1/2 in Dia
Gauge Type
Industrial Vacuum
Material
Stainless Steel
Series
Pro 200 Series
Sg Accuracy
+/-3-2-3% of Span +/-3% over First and Last Quarters of the Scale, +/-2% over the Middle Half of the Scale
Sg Male Connection
0.013 in Brass Throttle Plug

Similar Products

Model Number Measuring Range Connection Type Price Action
304SS 2.5

63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254A Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge

NPT

304SS 2.5

649065 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254M Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254P Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254U Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254H Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge

NPT

304SS 2.5

465866 Bottom Connect Pressure Gauge

MNPT

304SS 2.5

649140 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254CC Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254Q Bottom Connect Pressure Gauge

NPT

649157

649157

NPT

SS/BRASS, CENTER BACK, 2 1/2 DIAL, 1/4

PRO-201L-254T

NPT

Product Questions & Answers (2)

Question by: Duane R on Dec 9, 2025, 9:31 AM
What size is that bottom connection?
Answer by: Customer Support on Dec 11, 2025, 8:51 AM
This gauge uses a 1/4 NPT bottom connection.
Question by: Floyd W on Nov 12, 2025, 9:49 AM
Got a pump setup that vibrates pretty bad during operation, will a liquid filled gauge actually hold up to that, or am I gonna be replacing it every few months?
Answer by: Customer Support on Nov 14, 2025, 6:38 AM
Liquid fill is specifically what you want for high-vibration environments. The glycerin inside dampens needle movement caused by pulsation and vibration, which protects the internal mechanism from the kind of wear that kills dry gauges quickly. That said, if your system has pulsation present, keep your operating pressure at or below 50% of the full-scale range, so no more than 50 PSI on this gauge, to get the best service life out of it.
