304SS 2.5" 0-600 PSI/ 0-40 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

The 304 stainless steel construction ensures durability and resistance to corrosion crucial for demanding environments. This liquid-filled gauge features a 2.5-inch dial and a bottom 1/4 NPT brass connection providing clear readings and reliable performance. With an accuracy of 3-2-3% of span this gauge is designed to measure pressures ranging from 0 to 600 PSI or 0 to 40 Bar. The polycarbonate window offers additional protection while the liquid filling helps to dampen vibrations and pulsations enhancing the readability and lifespan of the device. ENGINEERED Speciality Products designed this gauge to maintain optimal performance within a pressure range of 25% to 75% of its maximum scale. The dimensions are A: 2.48 B: 1.21 C: 2.71 D: 0.46 making it compact yet highly efficient for its intended applications. MPN: 63 1008AL 02L 600#-9824 Supplier Part Number: PRO-201L-254K

Specifications

Calibrated No	Case Included No	Dimensions A=2.48 B=1.21 C=2.71 D=0.46	Brand Engineered Specialty Products – Esp	Brand Engineered Specialty Products	Pack Size 1.00	UOM EA	Fill Type Liquid Filled	Materials 304SS	Specifications 2.5" 0-600 PSI/ 0-40 Bar	Supplier Part Number PRO-201L-254K	Thread 1 1/4 NPT	Alternate Part Numbers Alternate Part Number 574131, Alternate Part Number 631008AL02L600#-9824, Alternate Part Number 638008A4G02LP0LBR600242-12, Alternate Part Number 649089, Alternate Part Number C1ND93, Alternate Part Number MI-08734404, Alternate Part Number MINO-01117X96008	Product Weight 0.99 lbs

Similar Products

Model Number	Part Number	Specifications	Fill Type	Thread 1	Materials	Dimensions
PRO-201L-254U Bottom Connect Pressure Gauge	PRO-201L-254U	2.5" 0-10,000 PSI/ 0-700 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
465866 Bottom Connect Pressure Gauge	465866	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge	PRO-201L-254B	2.5" 0-15 PSI / 0-1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge	PRO-201L-254F	2.5" 0-160 PSI/ 0-11 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H Bottom Connect Pressure Gauge	PRO-201L-254H	2.5" 0-300 PSI/ 0-20 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254A Bottom Connect Pressure Gauge	PRO-201L-254A	2.5" 0 - 30Hg/ 0- -1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC Bottom Connect Pressure Gauge	PRO-201L-254CC	2.5" 30Hg-30 PSI/ -1.0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M Bottom Connect Pressure Gauge	PRO-201L-254M	2.5" 0-1,000 PSI/ 0-70 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649027 Bottom Connect Pressure Gauge	649027	2.5" 0-100 PSI/ 0-7 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge	PRO-201L-254O	2.5" 0-2,000 PSI/ 0-140 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge	PRO-201L-254CB	2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q Bottom Connect Pressure Gauge	PRO-201L-254Q	2.5" 0-4,000 PSI/ 0-280 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649140 Bottom Connect Pressure Gauge	649140	2.5" 0-5,000 PSI/ 0-350 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge	PRO-201L-254V	2.5" 0-15,000 PSI/ 0-1000 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649065 Bottom Connect Pressure Gauge	649065	2.5" 0-200 PSI/ 0-14 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge	648990	2.5" 0-30 PSI/ 0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge	649010	2.5" 0-60 PSI/ 0-4.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P Bottom Connect Pressure Gauge	PRO-201L-254P	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge	PRO-201L-254K	2.5" 0-600 PSI/ 0-40 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge	PRO-201L-254N	2.5" 0-1,500 PSI/ 0-100 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46

Product Questions & Answers (3)

Question by: Carl E on Feb 3, 2026, 6:05 AM

Running this on a hydraulic press that throws a fair amount of vibration. liquid filled help with that, or am I gonna be replacing it regular?

Answer by: Customer Support on Feb 4, 2026, 1:24 PM

Liquid filling is exactly what handles that kind of environment. The glycerin or oil inside dampens the needle movement caused by vibration and pressure pulsations, which keeps the internal mechanism from wearing out as fast as a dry gauge would. You'll get cleaner readings and a longer service life running it on equipment that cycles hard. One thing worth keeping in mind: if your system regularly runs near that 600 PSI ceiling, pull it back. Normal operation works best between 25% and 75% of the full scale, so keeping your working pressure somewhere in the 150 to 450 PSI range will do the most to extend its life.

Question by: Randy B on Aug 17, 2025, 8:19 AM

got a spot for a bottom-mount gauge with 1/4 NPT threads. is this one a match, and what’s the dial size?

Answer by: Customer Support on Aug 18, 2025, 4:46 PM

It uses a 1/4 NPT bottom connection with a male brass connector. The face is a 2.5 inch dial.

Question by: Glen G on Sep 2, 2025, 3:42 PM

Reckon this gauge would hold up okay outside, or is it more for indoor use?

Answer by: Customer Support on Sep 4, 2025, 6:46 AM

The 304 stainless steel construction is designed to offer good durability and corrosion resistance, which should help it hold up reasonably well in many outdoor environments. Just keep in mind the normal operating pressure recommendation of 25%-75% of the scale.
