304SS 2.5" 0-1,000 PSI/ 0-70 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Ask A Question

Description & Features

The 304SS 2.5" 0-1 000 PSI/ 0-70 Bar Liquid Filled Pressure Gauge with 1/4 NPT bottom connection offers precision and durability for industrial applications. Crafted from high-quality 304 stainless steel this gauge ensures longevity and resistance to harsh environments.

Featuring a 2.5" dial this gauge provides clear readability. The liquid-filled design enhances performance by dampening vibrations and impacts maintaining accuracy and reliability. The pressure range of 0-1 000 PSI (0-70 Bar) makes it suitable for various industrial settings.

Its brass male connection with a 0.013" throttle plug ensures secure fitting. The polycarbonate window offers transparency and durability. The accuracy is 3-2-3% of the span ensuring reliable measurements across different pressure points.

Supplier Part Number: PRO-201L-254M

Specifications

a Dimensions
2.48 in
b Dimensions
1.21 in
c Dimensions
2.71 in
Calibrated
Without Calibrated
Case Included
Without Case
Connection Type
NPT
d Dimensions
0.46 in
Dial Face
Polycarbonate
Dimensions
2.65 in H x 1.21 in W
Fill Medium
Glycerin
Fill Type
Liquid Filled
Gauge Type
Industrial Vacuum
Material
Stainless Steel
Series
Pro 200 Series
Sg Accuracy
+/-3-2-3% of Span +/-3% over First and Last Quarters of the Scale, +/-2% over the Middle Half of the Scale
Sg Male Connection
0.013 in Brass Throttle Plug

Product Questions & Answers (3)

Sign In Hover me Please sign in to submit a question
Question by: Ralph M on Dec 18, 2025, 8:18 PM
got a spot with a 1/4 NPT port on the bottom, will this gauge screw right in or am i missing something
Answer by: Customer Support on Dec 19, 2025, 8:54 PM
With a 1/4 NPT bottom connection and a male brass fitting, it’s set up to thread directly into a 1/4 NPT female port. It also includes a 0.013 inch throttle plug in that male connection.
Question by: Lee S on Jul 31, 2025, 11:56 AM
gauge says liquid filled -- what's actually in it and why does that matter for something like a hydraulic press setup?
Answer by: Customer Support on Aug 1, 2025, 12:55 PM
Liquid-filled gauges use glycerin or a similar fluid sealed inside the case to cushion the needle against vibration and pressure spikes. On hydraulic press equipment where you get repeated surges, that dampening effect keeps the needle readable and protects the internal movement from wearing out prematurely. A dry gauge in the same application tends to flutter and lose accuracy a lot faster.
Question by: Gene H on Jun 7, 2025, 3:38 PM
Reckon this'll hold up okay outside? We get some nasty weather 'round here.
Answer by: Customer Support on Jun 8, 2025, 8:20 PM
Crafted from 304 stainless steel, this gauge offers good longevity and resistance to harsh environments.
