304SS 2.5" 0-2,000 PSI/ 0-140 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

Crafted with precision this pressure gauge features a 304 stainless steel construction designed for resilience in demanding environments. Its liquid-filled design ensures accurate readings by dampening the effects of vibration and pulsation. The 2.5-inch dial provides clear readings up to 2 000 PSI (0-140 Bar) with a 3-2-3% accuracy spanning the gauge scale. The polycarbonate window enhances durability providing a robust barrier against harsh conditions. The 1/4 NPT bottom connection made of brass is equipped with a 0.013" throttle plug ensuring reliable and consistent measurements. ENGINEERED SPECIALTY PRODUCTS has designed this gauge for industrial applications requiring precise pressure monitoring. Dimensions are compact with A=2.48 B=1.21 C=2.71 and D=0.46 inches making it suitable for tight spaces. For optimal use it is recommended that the normal operating pressure be confined to 25%-75% of the scale with a reduced maximum operating gauge pressure to 50% in the presence of pulsation.

Model Number: 63 1008AL 02L 2000#-9827

Supplier Part Number: PRO-201L-254O

Specifications

Calibrated No	Case Included No	Dimensions A=2.48 B=1.21 C=2.71 D=0.46	Brand Engineered Specialty Products – Esp	Brand Engineered Specialty Products	Pack Size 1.00	UOM EA	Fill Type Liquid Filled	Materials 304SS	Specifications 2.5" 0-2,000 PSI/ 0-140 Bar	Supplier Part Number PRO-201L-254O	Thread 1 1/4 NPT	Alternate Part Numbers Alternate Part Number 201L-254O, Alternate Part Number 574315, Alternate Part Number 638008A4G02LP0LBR2000242-15, Alternate Part Number 649119, Alternate Part Number C1ND96	Product Weight 0.99 lbs

Similar Products

Model Number	Part Number	Specifications	Fill Type	Thread 1	Materials	Dimensions
PRO-201L-254U Bottom Connect Pressure Gauge	PRO-201L-254U	2.5" 0-10,000 PSI/ 0-700 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
465866 Bottom Connect Pressure Gauge	465866	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge	PRO-201L-254B	2.5" 0-15 PSI / 0-1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge	PRO-201L-254F	2.5" 0-160 PSI/ 0-11 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254H Bottom Connect Pressure Gauge	PRO-201L-254H	2.5" 0-300 PSI/ 0-20 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254A Bottom Connect Pressure Gauge	PRO-201L-254A	2.5" 0 - 30Hg/ 0- -1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254CC Bottom Connect Pressure Gauge	PRO-201L-254CC	2.5" 30Hg-30 PSI/ -1.0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254M Bottom Connect Pressure Gauge	PRO-201L-254M	2.5" 0-1,000 PSI/ 0-70 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649027 Bottom Connect Pressure Gauge	649027	2.5" 0-100 PSI/ 0-7 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge	PRO-201L-254O	2.5" 0-2,000 PSI/ 0-140 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge	PRO-201L-254CB	2.5" 30Hg-15 PSI/ -1.0 - 1.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254Q Bottom Connect Pressure Gauge	PRO-201L-254Q	2.5" 0-4,000 PSI/ 0-280 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649140 Bottom Connect Pressure Gauge	649140	2.5" 0-5,000 PSI/ 0-350 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge	PRO-201L-254V	2.5" 0-15,000 PSI/ 0-1000 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
649065 Bottom Connect Pressure Gauge	649065	2.5" 0-200 PSI/ 0-14 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge	648990	2.5" 0-30 PSI/ 0-2.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge	649010	2.5" 0-60 PSI/ 0-4.0 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
PRO-201L-254P Bottom Connect Pressure Gauge	PRO-201L-254P	2.5" 0-3,000 PSI/ 0-210 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge	PRO-201L-254K	2.5" 0-600 PSI/ 0-40 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46
63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge	PRO-201L-254N	2.5" 0-1,500 PSI/ 0-100 Bar	Liquid Filled	1/4 NPT	304SS	A=2.48 B=1.21 C=2.71 D=0.46

Product Questions & Answers (2)

Question by: Glen M on Sep 11, 2025, 5:00 PM

gauge says liquid filled, what's actually in there and does it help when lines are hammering pretty bad?

Answer by: Customer Support on Sep 13, 2025, 6:32 AM

Liquid fill in gauges like this one is typically glycerin, and yes, it makes a real difference when you've got pulsation or vibration in the line. The fluid inside dampens the needle movement so you're getting a stable, readable measurement instead of a needle bouncing all over the place. That said, the product does call out a specific limit worth knowing: if pulsation is present, keep your operating pressure at or below 50% of the full scale. On a 2,000 PSI gauge, that puts your safe working ceiling at 1,000 PSI under those conditions. The 0.013" throttle plug in the brass bottom connection also helps slow pressure spikes from reaching the internals too fast.

Question by: Dwight K on Jul 1, 2025, 4:39 PM

reckon this gauge will hold up okay outside?

Answer by: Customer Support on Jul 2, 2025, 8:04 PM

Crafted from 304 stainless steel, this gauge is designed for resilience in demanding environments. The polycarbonate window further enhances its durability.
