304SS 2.5" 0-10,000 PSI/ 0-700 Bar Liquid Filled Pressure Gauge, 1/4 NPT Bottom Connection

Description & Features

Constructed from durable 304 stainless steel this 2.5" liquid-filled pressure gauge is engineered for high-pressure environments providing precise measurement up to 10 000 PSI or 700 Bar. The polycarbonate window offers clarity and resistance to impact ensuring long-lasting visibility of readings.

Featuring a 1/4 NPT brass male connection this gauge is designed for straightforward and secure connections. With an accuracy of 3-2-3% of span it delivers dependable performance across a variety of pressure ranges.

Liquid filling minimizes the impact of vibration and pulsation enhancing the gauge's durability. The dimensions are A=2.48 B=1.21 C=2.71 and D=0.46. Recommended normal operating pressure should be between 25%-75% of the scale range and not exceed 50% if pulsation is present.

Supplier Part Number: PRO-201L-254U

Specifications

Brand
PIC Gauges
a Dimensions
2.48 in
b Dimensions
1.21 in
c Dimensions
2.71 in
Calibrated
Without Calibrated
Case Included
Without Case
Connection Type
NPT
d Dimensions
0.46 in
Dial Face
Polycarbonate
Dimensions
2.65 in H x 1.21 in W
Fill Medium
Glycerin
Fill Type
Liquid Filled
Gauge Size
2-1/2 in Dia
Gauge Type
Industrial Vacuum
Material
Stainless Steel
Series
Pro 200 Series
Sg Accuracy
+/-3-2-3% of Span +/-3% over First and Last Quarters of the Scale, +/-2% over the Middle Half of the Scale
Sg Male Connection
0.013 in Brass Throttle Plug

Similar Products

Model Number Measuring Range Connection Type Price Action
304SS 2.5

649027 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 160#-9821 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 2000#-9827 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254A Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15#/V-9816 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 60#-9819 Bottom Connect Pressure Gauge

NPT

304SS 2.5

649065 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254M Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15#-9815 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254P Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 15000#-9833 Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 1500#-9826 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254H Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 30#-9817 Bottom Connect Pressure Gauge

NPT

304SS 2.5

465866 Bottom Connect Pressure Gauge

MNPT

304SS 2.5

649140 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254CC Bottom Connect Pressure Gauge

NPT

304SS 2.5

63 1008AL 02L 600#-9824 Bottom Connect Pressure Gauge

NPT

304SS 2.5

PRO-201L-254Q Bottom Connect Pressure Gauge

NPT

649157

649157

NPT

SS/BRASS, CENTER BACK, 2 1/2 DIAL, 1/4

PRO-201L-254T

NPT

Product Questions & Answers (2)

Question by: Larry H on Jan 21, 2026, 10:57 AM
got a 1/4 NPT port on the bottom of my line, is this gauge set up to screw right in?
Answer by: Customer Support on Jan 23, 2026, 10:06 AM
It uses a 1/4 NPT male bottom connection, so it threads into a matching 1/4 NPT female port.
Question by: Clint T on Nov 7, 2025, 4:39 PM
What kind of environments can this handle? I'm thinking about vibration specifically.
Answer by: Customer Support on Nov 9, 2025, 11:05 AM
Liquid filling minimizes the impact of both vibration and pulsation, which enhances the gauge's durability in tougher environments.
