main product photo

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/8-27 Male NPT, Straight

Ask A Question

Description & Features

The Brass Push>Connect Air Brake Tube Fitting is a durable solution for air brake systems. Designed for seamless connectivity it features a 0.38 inch tube OD and a 1/8-27 male NPT thread offering easy and fast assembly in varied industrial applications.

Constructed from CA360 brass for its body and collet this fitting ensures reliability and long-lasting performance. The EP O-ring provides a secure seal supporting a pressure range from vacuum to 150 psi and a temperature tolerance ranging from -40F to +200F.

Engineered for moderate vibration resistance this fitting meets D.O.T. FMVSS 571.106 and SAE J1131 air brake system performance requirements. The straight connection design allows for efficient installation and reusability in the field.

Conformance: Meets D.O.T. FMVSS 571.106 and SAE J1131 air brake system performance requirements.

Disassembly: 1. Ensure no air pressure is present. 2. Depress collet head using fingers or an Eaton tube release tool to release tubing grip. 3. With the collet depressed remove the tubing from the fitting.

Assembly Instructions: 1. Make a square cut edge on the tube using a tube cutter (maximum 15 cutting angle allowed). 2. Insert tubing straight into the fitting until a solid stop is felt. 3. Gently tug on the tubing to ensure it is secure.

Supplier Part Number: 1868X6X2

Materials: CA360 Brass (Body & Collet) EP (Ethylene Propylene) O-ring.

Brand: Danfoss Power Solutions (Aeroquip Inc-Alternate)

Specifications

Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
L
1.33
Supplier Part Number
1868X6X2
Thread 1
1/8-27
Tube O.D.
0.38
Tube O.D.
0.375
Alternate Part Numbers
Alternate Part Number C1HN21, Alternate Part Number MI-04494597, Alternate Part Number MINO-00925X94001
Product Weight
0.08 lbs

Related Documents

Similar Products

Model Number Tube O.D. Thread 1 L Price Action
Brass Push>Connect Air Brake Tube Fitting, 0.25 Inch Tube OD To 1/8-27 Male NPT, Straight

1868X4 Brass Push>Connect To Male NPT Fitting

0.25

1/8-27

0.95

Brass Push>Connect Air Brake Tube Fitting, 0.63 Inch Tube OD To 1/2-14 Male NPT, Straight

1868X10 Brass Push>Connect To Male NPT Fitting

0.625

1/2-14

1.71

Brass Push>Connect Air Brake Tube Fitting, 0.63 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X10X6 Brass Push>Connect To Male NPT Fitting

0.625

3/8-18

1.72

Brass Push>Connect Air Brake Tube Fitting, 0.16 Inch Tube OD To 1/16 Male NPT, Straight

1868X2.5X1 Brass Push>Connect To Male NPT Fitting

0.1563

1/16

0.92

Brass Push>Connect Air Brake Tube Fitting, 0.25 Inch Tube OD To 1/4-28 Male NPT, Straight

1868X4X4 Brass Push>Connect To Male NPT Fitting

0.25

1/4-28

1.18

Brass Push>Connect Air Brake Tube Fitting, 0.25 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X4X6 Brass Push>Connect To Male NPT Fitting

0.25

3/8-18

1.27

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/4-18 Male NPT, Straight

1868X6 Brass Push>Connect To Male NPT Fitting

0.375

1/4-18

1.29

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/8-27 Male NPT, Straight

1868X6X2 Brass Push>Connect To Male NPT Fitting

0.375

1/8-27

1.33

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X6X6 Brass Push>Connect To Male NPT Fitting

0.375

3/8-18

1.27

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/2-14 Male NPT, Straight

1868X6X8 Brass Push>Connect To Male NPT Fitting

0.375

1/2-14

1.47

Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X8 Brass Push>Connect To Male NPT Fitting

0.5

3/8-18

1.35

Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 1/4-18 Male NPT, Straight

1868X8X4 Brass Push>Connect To Male NPT Fitting

0.5

1/4-18

1.46

Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 1/2-14 Male NPT, Straight

1868X8X8 Brass Push>Connect To Male NPT Fitting

0.5

1/2-14

1.5

Product Questions & Answers (2)

Question by: Frank R on Feb 6, 2026, 7:26 PM
fitting says it handles up to 150 psi, is that enough for a standard air brake setup, or do I need something heavier duty?
Answer by: Customer Support on Feb 8, 2026, 6:25 AM
For most air brake systems running at typical operating pressures, 150 psi is right in the wheelhouse. The fitting also handles vacuum on the low end, so you've got full range coverage across normal brake system conditions. It carries both D.O.T. FMVSS 571.106 and SAE J1131 ratings, which are the recognized performance standards for air brake applications, so it's built to spec for that kind of service.
Question by: Cody P on Nov 7, 2025, 10:58 AM
got 3/8 air brake tube. will this push connect fitting screw into a 1/8-27 npt port and go straight in?
Answer by: Customer Support on Nov 9, 2025, 6:48 AM
It is set up for 0.38 inch tube OD on the push-to-connect side and a 1/8-27 male NPT thread on the other end, in a straight connector layout.
