Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 1/4-18 Male NPT, Straight

Ask A Question

Description & Features

The Brass Push>Connect Air Brake Tube Fitting is a robust solution designed for seamless air brake system integration. Engineered from CA360 brass this fitting ensures durability and reliable performance. It fits a 0.50-inch tube OD and a 1/4-18 Male NPT connection.

This fitting meets D.O.T. FMVSS 571.106 and SAE J1131 requirements making it a dependable choice for air brake applications. Featuring an easy fast assembly it includes a one-piece fitting that is also field serviceable and reusable.

With a temperature range from -40F to +200F and moderate vibration resistance this air brake fitting is versatile across various demanding environments. It offers a vacuum to 150 psi pressure range.

Materials used include ethylene propylene O-ring for a secure seal.

Assembly Instructions: 1. Use a tube cutter to make a square cut (max 15 angle). 2. Insert tubing into fitting until a solid stop is felt. 3. Tug the tubing gently to confirm secure fitting.

Disassembly: 1. Ensure no air pressure is present. 2. Depress the collet head using fingers or a release tool. 3. Pull the tubing from the fitting while the collet is depressed.

Supplier Part Number: 1868X8X4

Specifications

Brand
Danfoss Power Solutions (II LLC Aeroquip)
Brand
Aeroquip
Pack Size
1.00
UOM
EA
L
1.46
Supplier Part Number
1868X8X4
Thread 1
1/4-18
Tube O.D.
0.50
Tube O.D.
0.5
Alternate Part Numbers
Alternate Part Number C1HN25, Alternate Part Number MI-02753986, Alternate Part Number MINO-00925X10263
Product Weight
0.11 lbs

Related Documents

Similar Products

Model Number Tube O.D. Thread 1 L Price Action
Brass Push>Connect Air Brake Tube Fitting, 0.25 Inch Tube OD To 1/8-27 Male NPT, Straight

1868X4 Brass Push>Connect To Male NPT Fitting

0.25

1/8-27

0.95

Brass Push>Connect Air Brake Tube Fitting, 0.63 Inch Tube OD To 1/2-14 Male NPT, Straight

1868X10 Brass Push>Connect To Male NPT Fitting

0.625

1/2-14

1.71

Brass Push>Connect Air Brake Tube Fitting, 0.63 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X10X6 Brass Push>Connect To Male NPT Fitting

0.625

3/8-18

1.72

Brass Push>Connect Air Brake Tube Fitting, 0.16 Inch Tube OD To 1/16 Male NPT, Straight

1868X2.5X1 Brass Push>Connect To Male NPT Fitting

0.1563

1/16

0.92

Brass Push>Connect Air Brake Tube Fitting, 0.25 Inch Tube OD To 1/4-28 Male NPT, Straight

1868X4X4 Brass Push>Connect To Male NPT Fitting

0.25

1/4-28

1.18

Brass Push>Connect Air Brake Tube Fitting, 0.25 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X4X6 Brass Push>Connect To Male NPT Fitting

0.25

3/8-18

1.27

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/4-18 Male NPT, Straight

1868X6 Brass Push>Connect To Male NPT Fitting

0.375

1/4-18

1.29

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/8-27 Male NPT, Straight

1868X6X2 Brass Push>Connect To Male NPT Fitting

0.375

1/8-27

1.33

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X6X6 Brass Push>Connect To Male NPT Fitting

0.375

3/8-18

1.27

Brass Push>Connect Air Brake Tube Fitting, 0.38 Inch Tube OD To 1/2-14 Male NPT, Straight

1868X6X8 Brass Push>Connect To Male NPT Fitting

0.375

1/2-14

1.47

Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 3/8-18 Male NPT, Straight

1868X8 Brass Push>Connect To Male NPT Fitting

0.5

3/8-18

1.35

Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 1/4-18 Male NPT, Straight

1868X8X4 Brass Push>Connect To Male NPT Fitting

0.5

1/4-18

1.46

Brass Push>Connect Air Brake Tube Fitting, 0.50 Inch Tube OD To 1/2-14 Male NPT, Straight

1868X8X8 Brass Push>Connect To Male NPT Fitting

0.5

1/2-14

1.5

Product Questions & Answers (2)

Question by: Phil A on Dec 17, 2025, 9:30 AM
got 1/2 inch air brake tubing already on the truck, will this fitting thread into a 1/4-18 npt port?
Answer by: Customer Support on Dec 19, 2025, 6:59 AM
Fits 0.50 inch tube OD on the push to connect side and has 1/4-18 male NPT threads on the other side, so it’s meant to go into a 1/4-18 NPT female port.
Question by: Debbie B on Sep 15, 2025, 7:04 AM
What kind of temperatures can this handle? Just makin' sure it'll hold up in the cold.
Answer by: Customer Support on Sep 16, 2025, 2:37 PM
This fitting is rated for temperatures ranging from -40F to +200F, making it suitable for a variety of demanding environments.
