Brass Push-In Tube Fitting, 0.25 Tube OD to 1/4-18 Female NPT, Straight Bulkhead

Ask A Question

Description & Features

Designed for quick, tool-free tube connections, this Brass Push-In Tube Fitting, 0.25 Tube OD to 1/4-18 Female NPT, Straight Bulkhead from Alkon Corp provides a reliable, leak-proof seal in pneumatic and fluid line installations. Brass construction offers durability across a wide range of industrial environments, with Buna-N O-rings standard for consistent sealing performance.

The push-in mechanism grips the tube automatically upon insertion, pulling force or line pressure only tightens the hold. A positive tube stop and interior camming surface work together to prevent leakage under working conditions. Pre-applied Teflon-based sealant on all male threads simplifies installation. Compatible with polyurethane tubing (90 durometer and above), polybutylene tubing, and soft metal tubing. Rated for use from -10°F to 200°F, and suitable for vacuum service.

SKU: AQ86-P-4X4

Supplier Part Number (MPN): AQ86-P-4X4

Alternate Part Numbers: C1CK58, MI-00293988, MINO-00034F41667

Specifications

Brand
ALKON
a Dimensions
1.46 in
Connection Size 1
1/4 in
Connection Size 2
1/4 in
Connection Size 3
1/2 in
Connection Type
FNPT, Push-Fit
Connection Type 1
Push-to-Connect Tube
Connection Type 2
FNPT
d Dimensions
0.63 in
Dimensions
1.81 in L
Fitting Type
Union
For Use With
Polybutylene and Soft Metal Tubing
Material
Brass
Material Construction
Brass
Series
AQ Series
Sg How It Works
When Tubing (1) is Inserted into the Fitting, it First Passes Through the Gripping Teeth (2), Just Beyond the Gripping Teeth is the O-ring (3) Which Provides the Leak Proof Seal Against the OD, of the Tube, the Gripping Teeth Grab the Tube, Which Expands
Thread Size
1/2-20
Tube OD
1/4 in

Similar Products

Model Number Tube O.D. Thread Size a Dimensions Thread 2 d Dimensions Price Action
Brass Push-In Tube Fitting, 0.38 Tube OD to 1/4-18 Female NPT, Straight Bulkhead

AQ86-P-6X4 Brass Push-In To Female NPT Bulkhead

0.38

1/4-18 x 5/8-18

1.89 in

5/8-18

0.99 in

Product Questions & Answers (2)

Question by: Travis A on Sep 21, 2025, 1:33 PM
If I'm using this bulkhead fitting with some soft metal tubing, will it still hold okay?
Answer by: Customer Support on Sep 22, 2025, 6:35 PM
This fitting is compatible with soft metal tubing, as well as polyurethane (90 durometer and above) and polybutylene tubing. The push-in design grips the tube automatically upon insertion and only tightens with pulling force or line pressure.
Question by: Kent R on Jun 25, 2025, 7:34 AM
got 1/4" OD poly tube, does this fitting actually bite and seal without clamps or anything?
Answer by: Customer Support on Jun 26, 2025, 8:05 PM
Once the tube is pushed in, the gripping teeth grab the outside of the tubing and a Buna-N O-ring seals on the tube OD. Pulling on the tube or having pressure in the line only tightens the grip because the insert cams in deeper, and the tube bottoms on a positive stop for support.
