Brass Short Shank Type Fitting, 0.31 Inch Hose ID to 5/8-18 SAE 45 deg Flare, Straight

Ask A Question

Description & Features

This Dixon Valve & Coupling brass fitting features a short shank and is suitable for low-pressure fluid transfer, suction, and discharge applications. Constructed from machined free-cutting brass rod CDA 360 alloy, this fitting connects a 0.31 inch hose ID to a 5/8-18 SAE 45 degree flare. The Brass Short Shank Type Fitting is part of the Short Shank Brass Industrial Hose Fittings product model line.

Dimensions include a C measurement of 1.27 inches and an E measurement of 0.97 inches.

SKU: 144-0510

Supplier Part Number (MPN): 1440510K

Alternate Part Numbers: C1FS80, MI-00362005, MINO-00056F96410

Specifications

C
1.27
E
0.97
Brand
Dixon Valve & Co
Brand
Dixon Valve & Co
Pack Size
1.00
UOM
EA
Finish
No
Hose I.D.
0.31
Supplier Part Number
1440510K
Alternate Part Numbers
Alternate Part Number C1FS80, Alternate Part Number MI-00362005, Alternate Part Number MINO-00056F96410
Product Weight
0.07 lbs

Similar Products

Model Number Finish Hose I.D. Thread 1 C E Price Action
Brass Short Shank Type Fitting, 0.25 Inch Hose ID to 7/16-20 SAE 45 deg Flare, Straight

143-0407 Brass Shank SAE 45 deg Fitting

No

0.25

7/16-20

1.25

0.97

Brass Short Shank Type Fitting, 0.25 Inch Hose ID to 1/2-20 SAE 45 deg Flare, Straight

143-0408 Brass Shank SAE 45 deg Fitting

No

0.25

1/2-20

1.31

0.97

Brass Short Shank Type Fitting, 0.31 Inch Hose ID to 1/2-20 SAE 45 deg Flare, Straight

143-0508 Brass Shank SAE 45 deg Fitting

No

0.313

1/2-20

1.31

0.97

Brass Short Shank Type Fitting, 0.38 Inch Hose ID to 3/4-16 SAE 45 deg Flare, Straight

143-0612 Brass Shank SAE 45 deg Fitting

No

0.375

3/4-16

1.34

0.97

Brass Short Shank Type Fitting, 0.50 Inch Hose ID to 3/4-16 SAE 45 deg Flare, Straight

143-0812 Brass Shank SAE 45 deg Fitting

No

0.5

3/4-16

1.34

0.97

Brass Short Shank Type Fitting, 0.50 Inch Hose ID to 7/8-14 SAE 45 deg Flare, Straight

143-0814 Brass Shank SAE 45 deg Fitting

No

0.5

7/8-14

1.34

0.97

Brass Short Shank Type Fitting, 0.25 Inch Hose ID to 5/8-18 SAE 45 deg Flare, Straight

144-0410 Brass Shank SAE 45 deg Fitting

No

0.25

5/8-18

1.27

0.97

Brass Short Shank Type Fitting, 0.31 Inch Hose ID to 5/8-18 SAE 45 deg Flare, Straight

144-0510 Brass Shank SAE 45 deg Fitting

No

0.313

5/8-18

1.27

0.97

Brass Short Shank Type Fitting, 0.38 Inch Hose ID to 5/8-18 SAE 45 deg Flare, Straight

144-0610 Brass Shank SAE 45 deg Fitting

No

0.375

5/8-18

1.27

0.97

Product Questions & Answers (1)

Question by: Joyce G on Apr 18, 2025, 3:36 PM
Will this fitting hold up okay for transferring fluids at low pressure?
Answer by: Customer Support on Apr 19, 2025, 6:10 PM
Machined from free cutting brass rod CDA 360 alloy, this fitting is well-suited for low pressure fluid transfer, suction, and discharge applications. Just keep in mind that the working pressure can change based on the hose and clamps you use, plus how well everything's installed.
