Cable FELSTED PTO KNOB X0150.

Description & Features

The Cable FELSTED PTO KNOB X0150 features high-performance construction ideal for demanding industrial applications. Designed by Orscheln Products LLC this cable hardware offers superior flexibility and durability thanks to its advanced HP core available in 3 4 and 6 series.

Constructed with corrosion-resistant materials the end fittings ensure extended lifespan and reliable performance. The rods and sleeves are made from 300 series stainless steel while the hubs are crafted from aluminum or stainless steel providing robust protection against wear and tear.

With its heavy-duty thick-walled polymer jackets the FELSTED PTO KNOB X0150 ensures maximum cable strength. The reliable polymer liners function efficiently within a temperature range of -65F to 225F providing consistent performance under various conditions.

To safeguard against contaminants the product utilizes durable custom compounded seals while the exclusive polymer rod and sleeve bearing prevent metal-to-metal contact enhancing sealing and longevity. The stranded conduit made from multiple oil-tempered spring wires maintains flexibility and withstands extreme compressive and tensile loads.

MPN: C1EU72

Supplier Part Number: X0150

Specifications

Brand
ORSCHELN®
Sg Conduit Jacket
Heavy-Duty, Thick-walled Polymer Jackets are Extruded Onto the Stranded Liner for Maximum Cable Strength, Standard Material is Hope Molded to A Dark Maroon Color
Sg Core Construction
Hi-performance (Hp) 1 x 7 Coated Core is Available in 3, 4 and 6 Series Cables, HP Core Utilizes A Proprietary Coating over 1 x 7 Wire Rope Which Offers Improved Flexibility and Higher Push Loads than Armor Core Construction, Solid Stainless Steel Cores a
Sg End Fittings
Corrosion-resistant Materials are Used Throughout to Provide Maximum Life, Standard 3, 4 and 6 Series Rods and Sleeves are 300 Series Stainless Steel, While Hubs are Either Aluminum or Stainless
Sg Liners
All Cables Utilize Polymer Liners Which Have A Temperature Rating of -65 to 225 deg F, Factory Lubrication Provides Optimum Core Performance Without Requiring Further Service
Sg Rod Sleeve Bearing
An Exclusive Polymer Rod and Sleeve Bearing is Used to Improve Efficiency, Sealing and Cable Life by Preventing Metal to Metal Contact Between the Rod and Sleeve, They also Accurately Align the Rod with the Seal to Insure Superior Sealing and A Long Cable
Sg Seals Boots
Durable Custom Compounded Seals are Used to Prevent Moisture and Contaminants from Entering the Cable
Sg Stranded Conduit
Multiple, Oil Tempered Spring Wires are Placed in A Long Lay Pattern to Protect the Liner and Inner Core, Maintain Flexibility and Withstand Extreme Compressive and Tensile Loads, This Long Lay Construction Results in Minimal Deflections During Cable Oper

Similar Products

Model Number Thread Size Length For Use With Price Action
Cable FELSTED 3 SERIES CLAMP.

39001 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSED CLEVIS 5/16-24 TH.

000-69003-0001 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED ROD PIVOT.

000-49042-0000 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED STOP COLLAR.

30103 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED CABLE PART.

39006 Cable Hardware & Knob

#10-32 x 1/4-28

3 Series Solid Core Cables

Cable FELSTED PIVOT (4 SERIES).

000-49008-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED FRICTION CONTROL.

055887-000000 Cable Hardware & Knob

Cable FELSTED BALL JOINT.

000-69007-0000 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED SWITCH KIT.

000-50036-0001 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED BALL JOINT.

000-49006-0000 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED CLEVIS.

000-49003-0002 Cable Hardware & Knob

10-32

3 Series Solid Core Cables

Cable FELSTED X0276-1 SLEEVE 5 INCH TRAVEL.

40004-5 Cable Hardware & Knob

Cable FELSTED CABLE FIELD CLAMP 000-39030-0001.

39030-1 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED 3 SERIES SHIM.

39002 Cable Hardware & Knob

3 and 4 Series Solid Core Cables

Cable ORSCHELN FELSTED SERIES 3 CLEVIS.

000-39003-0001 Cable Hardware & Knob

10-32

3 Series Solid Core Cables

Cable FELSTED BALL JOINT 4 SERIES.

000-49007-0000 Cable Hardware & Knob

1/4-28 x 5/16-24

4 Series Solid Core Cables

Cable FELSTED PIVOT For SOLID CORE.

39011-2 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED LOCKING PIVOT.

39011-1 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED SLEEVE X0102.

40202 Cable Hardware & Knob

Cable FELSTED BLACK 1/4-20 PLAIN T HANDL.

49005-1011 Cable Hardware & Knob

1/4-20

Cable FELSTED TERMINAL EYE.

000-49004-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED RED PLAIN 1/4-20 X0081.

49005-2011 Cable Hardware & Knob

1/4-20

Cable FELSTED 4 SERIES ROD CLEVIS 1/4-28 THREA.

000-69003-0003 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED ROD CLEVIS 6 SERIES.

000-49003-0003 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED VALVE KIT.

000-59112-0000 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED CLEVIS.

000-89003-0002 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED X0220 RVC HUB.

40313-1 Cable Hardware & Knob

Cable FELSTED TERMINAL EYE.

000-69004-0004 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable ORSCHELN FELSTED CLEVIS 1/4-28 UNF-2B FE.

000-49003-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELST VLV OPER HUB X0147.

40203-10 Cable Hardware & Knob

Cable ORSCHELN FELSTED 4 SERIES CLAMP.

49001 Cable Hardware & Knob

4 Series Solid Core Cables

000-49004-0003

000-49004-0003

1/4-28

4 Series Solid Core Cables

FELSTED TERMINAL EYE

000-69004-0001

5/16-24

6 Series Solid Core Cables

Product Questions & Answers (3)

Question by: Ralph M on May 2, 2025, 6:34 PM
got a cable setup that sees a lot of grime and wet weather. what keeps this PTO knob cable from getting crud down inside it?
Answer by: Customer Support on May 4, 2025, 1:01 PM
To help keep moisture and contaminants out, it uses durable custom compounded seals, plus an exclusive polymer rod and sleeve bearing that prevents metal to metal contact and improves sealing.
Question by: Lynn R on Dec 11, 2025, 9:04 AM
what kind of temp range does the liner hold up to on this cable? trying to figure out if it'll handle our setup without breaking down
Answer by: Customer Support on Dec 12, 2025, 6:42 PM
Polymer liners on this cable are rated from -65°F up to 225°F. Factory lubrication comes applied at the time of manufacturing, so there's no need to grease or service the liner after installation. That range covers most industrial environments pretty comfortably, whether you're dealing with cold storage conditions or equipment that runs hot during heavy use.
Question by: Ronnie W on Feb 2, 2026, 7:06 AM
What kind of operating temperatures can this Felsted PTO knob handle?
Answer by: Customer Support on Feb 3, 2026, 9:52 AM
These cables use polymer liners rated to operate from -65°F up to 225°F.
