Cable FELSTED SLEEVE X0102.

Description & Features

The Orscheln Products Cable FELSTED SLEEVE X0102 is manufactured with corrosion-resistant materials for maximum service life. The rod and sleeve bearing features a polymer construction improving sealing, efficiency, and cable life, while preventing metal-to-metal contact between the rod and sleeve.

This cable hardware features a heavy-duty, thick-walled polymer jacket extruded onto the stranded liner for maximum strength. It also utilizes polymer liners with a temperature rating of -65°F to 225°F.

SKU: 40202

Supplier Part Number (MPN): X0102

Alternate Part Numbers: C1KK26

Specifications

Brand
ORSCHELN®
Sg Conduit Jacket
Heavy-Duty, Thick-walled Polymer Jackets are Extruded Onto the Stranded Liner for Maximum Cable Strength, Standard Material is Hope Molded to A Dark Maroon Color
Sg Core Construction
Hi-performance (Hp) 1 x 7 Coated Core is Available in 3, 4 and 6 Series Cables, HP Core Utilizes A Proprietary Coating over 1 x 7 Wire Rope Which Offers Improved Flexibility and Higher Push Loads than Armor Core Construction, Solid Stainless Steel Cores a
Sg End Fittings
Corrosion-resistant Materials are Used Throughout to Provide Maximum Life, Standard 3, 4 and 6 Series Rods and Sleeves are 300 Series Stainless Steel, While Hubs are Either Aluminum or Stainless
Sg Liners
All Cables Utilize Polymer Liners Which Have A Temperature Rating of -65 to 225 deg F, Factory Lubrication Provides Optimum Core Performance Without Requiring Further Service
Sg Rod Sleeve Bearing
An Exclusive Polymer Rod and Sleeve Bearing is Used to Improve Efficiency, Sealing and Cable Life by Preventing Metal to Metal Contact Between the Rod and Sleeve, They also Accurately Align the Rod with the Seal to Insure Superior Sealing and A Long Cable
Sg Seals Boots
Durable Custom Compounded Seals are Used to Prevent Moisture and Contaminants from Entering the Cable
Sg Stranded Conduit
Multiple, Oil Tempered Spring Wires are Placed in A Long Lay Pattern to Protect the Liner and Inner Core, Maintain Flexibility and Withstand Extreme Compressive and Tensile Loads, This Long Lay Construction Results in Minimal Deflections During Cable Oper

Similar Products

Model Number Thread Size Length For Use With Price Action
Cable FELSTED 3 SERIES CLAMP.

39001 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSED CLEVIS 5/16-24 TH.

000-69003-0001 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED ROD PIVOT.

000-49042-0000 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED STOP COLLAR.

30103 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED CABLE PART.

39006 Cable Hardware & Knob

#10-32 x 1/4-28

3 Series Solid Core Cables

Cable FELSTED PIVOT (4 SERIES).

000-49008-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED FRICTION CONTROL.

055887-000000 Cable Hardware & Knob

Cable FELSTED BALL JOINT.

000-69007-0000 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED SWITCH KIT.

000-50036-0001 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED BALL JOINT.

000-49006-0000 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED CLEVIS.

000-49003-0002 Cable Hardware & Knob

10-32

3 Series Solid Core Cables

Cable FELSTED X0276-1 SLEEVE 5 INCH TRAVEL.

40004-5 Cable Hardware & Knob

Cable FELSTED CABLE FIELD CLAMP 000-39030-0001.

39030-1 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED 3 SERIES SHIM.

39002 Cable Hardware & Knob

3 and 4 Series Solid Core Cables

Cable ORSCHELN FELSTED SERIES 3 CLEVIS.

000-39003-0001 Cable Hardware & Knob

10-32

3 Series Solid Core Cables

Cable FELSTED BALL JOINT 4 SERIES.

000-49007-0000 Cable Hardware & Knob

1/4-28 x 5/16-24

4 Series Solid Core Cables

Cable FELSTED PIVOT For SOLID CORE.

39011-2 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED LOCKING PIVOT.

39011-1 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED BLACK 1/4-20 PLAIN T HANDL.

49005-1011 Cable Hardware & Knob

1/4-20

Cable FELSTED TERMINAL EYE.

000-49004-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED RED PLAIN 1/4-20 X0081.

49005-2011 Cable Hardware & Knob

1/4-20

Cable FELSTED 4 SERIES ROD CLEVIS 1/4-28 THREA.

000-69003-0003 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED ROD CLEVIS 6 SERIES.

000-49003-0003 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED VALVE KIT.

000-59112-0000 Cable Hardware & Knob

3 Series Solid Core Cables

Cable FELSTED CLEVIS.

000-89003-0002 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable FELSTED X0220 RVC HUB.

40313-1 Cable Hardware & Knob

Cable FELSTED TERMINAL EYE.

000-69004-0004 Cable Hardware & Knob

5/16-24

6 Series Solid Core Cables

Cable ORSCHELN FELSTED CLEVIS 1/4-28 UNF-2B FE.

000-49003-0001 Cable Hardware & Knob

1/4-28

4 Series Solid Core Cables

Cable FELSTED PTO KNOB X0150.

30162 Cable Hardware & Knob

Cable FELST VLV OPER HUB X0147.

40203-10 Cable Hardware & Knob

Cable ORSCHELN FELSTED 4 SERIES CLAMP.

49001 Cable Hardware & Knob

4 Series Solid Core Cables

000-49004-0003

000-49004-0003

1/4-28

4 Series Solid Core Cables

FELSTED TERMINAL EYE

000-69004-0001

5/16-24

6 Series Solid Core Cables

Product Questions & Answers (4)

Question by: Norm C on Nov 4, 2025, 3:18 PM
got a cable setup that sees a lot of grit and wet weather. what keeps this sleeve from getting nasty inside?
Answer by: Customer Support on Nov 5, 2025, 9:29 PM
To keep contamination out, it uses durable custom compounded seals and boots that help block moisture and debris from entering the cable.
Question by: Kurt T on Jun 28, 2025, 7:51 PM
What's the deal with the liners in these things? Are they gonna hold up in the heat?
Answer by: Customer Support on Jun 30, 2025, 7:44 AM
These cables use polymer liners rated to handle temperatures from -65°F up to 225°F, so they should definitely hold up well under typical operating conditions. They're also factory-lubricated for smooth performance without needing extra service.
Question by: Lyle H on Aug 15, 2025, 9:21 AM
got a push pull cable setup, what even is the Felsted sleeve X0102 used for?
Answer by: Customer Support on Aug 16, 2025, 5:02 PM
In a cable assembly, the sleeve is part of the cable hardware that supports the rod and helps keep things running smoothly at the end fitting. Orscheln uses corrosion resistant materials in their rods and sleeves, and their polymer rod and sleeve bearing is meant to prevent metal to metal contact, improve sealing, and extend cable life.
Question by: Darryl M on Feb 13, 2026, 12:52 PM
What's the sleeve made out of, and will it hold up if there's moisture getting into the cable area?
Answer by: Customer Support on Feb 15, 2026, 12:24 PM
Corrosion resistant materials are used throughout the rod and sleeve components, with standard sleeves in the 3, 4, and 6 series being 300 series stainless steel. On top of that, custom compounded seals and boots are built into the cable system specifically to keep moisture and contaminants from working their way inside. The polymer rod and sleeve bearing also helps seal things up by keeping metal-to-metal contact out of the equation entirely.
